High Quality Nickel Cobalt Beryllium Copper Alloy C17510/C17500

Product Description

Product Description NICKEL BERYLLIUM COPPER ALLOY(C17510)

Chemical composition(%)	Co	Ni	Be	Cu
	0.3	1.4-2.2	0.2-0.6	Balance

Material Characteritics

High thermal and electrical conductivity

Good strength and hardness

High tensile strenght

Very high hardness

Typical applications

Electrodes for spot welding, especially for stainless steel

Electrodes for projection welding

Butt welding jaws

Contact tips for submerged-arc-welding

Plunger tips for horizontal die-casting machines

Molds for NF-metal castings

Welding equipment

Current carry shafts

Plastic injection mold tooling

Robotics

Current carry bushings

Fabrication Properties

Technique	Suitability
Soldering	Good
Brazing	Good
Oxyacetylene welding	Not recommended
Gas shielded Arc welding	Fair
Coated metal Arc welding	Fair
Spot weld	Good
Seam weld	Fair
Butt weld	Fair

Capacity for being cold-worked	Excellent
Capacity for being hot-formed	Good
Machinability rating	Good

Introduction to Nickel Berrylium Copper (C17510)

Cobalt Beryllium Copper is primarily used in industry applications that require most high thermal or electrical conductivity, which features a cobalt alloying addition (2.40-2.70%). C17500 also Offers good strength and hardness characteristics plus conductivity in the range of 45-60 percent of copper with ultimate tensile and hardness properties approaching 140 ksi and RB 100 respectively.
