| US$99.00-9,999.00 | 1 Piece (MOQ) |
| Model | |
| Model No. | SVN-4K30U20P |
| Camera | |
| Image Sensor | 1/2.8" 4K/30fps Progressive Scan SONY IMX415 Image sensor |
| Pixels | 8MP |
| Video format (HD) | 3840*2160 25/30/29.97/23.98fps, 1920*1080 1280*720 25/30/29.97/23.98fps |
| Lens | |
| Optical lens | 20x optical zoom lens, 5.7±5%~94.4±5%mm |
| Optical zoom | 20X |
| Min. imaging distance | 0.2m (wide angle) - 1.5m (far end) |
| HOV | 55° (wide angle) - 3.9° (distal) |
| Focus | Automatic/manual/one-touch trigger |
| Min. illumination | 0.01lux (F1.8, AGC ON, color) |
| Exposure control | Auto/Manual/Shutter Priority/Aperture Priority/Brightness Control/Backlight Compensation |
| Electronic shutter | Auto/Manual, Shutter range: 1/1-1/30,000s |
| Gain | Auto/Manual |
| White balance | Auto/Manual/Auto Tracking White Balance/Indoor/Outdoor/One Touch |
| Effects Mode | Backlight compensation, horizontal mirroring, vertical flip |
| Digital noise reduction | 2D & 3D digital noise reduction |
| Signal-to-noise ratio | >55dB |
| Backlight Compensation | Off/On Automatic backlight compensation |
| Pan&Tilt | |
| Rotation speed | Horizontal: 2.2°~200°/sec, Vertical: 1.5° ~100°/sec |
| Corner range | Horizontal: ±170°, Vertical: -30°~90° |
| Preset point | 255 |
| Preset Accuracy | 0.1° |
| Video encoding | |
| Network Interface | |
| Video compression | H.265/H.264 |
| Resolution/frame rate | Main Stream: 3840*2160 25/30fps, (1920*1080,1280*720) 25/30fps Sub Stream: (704*576, 640*480, 640*360, 576*480, 352*288, 320*240, 320*180) 25/30fps |
| USB Interface | |
| Video compression | YUV/H.264/MJPEG |
| Resolution/frame rate | H.264: (3840*2160, 1920*1080, 1280*720, 800*600, 640*480, 704*576, 320*240) 25/30fps MJPEG: (3840*2160, 1920*1080, 1280*720, 800*600, 640*480, 704*576, 320*240) /25/30fps YUV: (3840*2160)15fps; (1920*1080, 1280*720, 800*600, 640*480, 704*576, 320*240) 25/30fps |
| Protocols | UVC1.1; UAC1.0 |
| Containment | Support zoom, PTZ control, adjustable brightness, contrast, hue, saturation, sharpness parameters |
| HDMI Interface | |
| Resolution/frame rate | 3840*2160 25/30/29.97/23.98fps; 1920*1080 1280*720 25/30/29.97/23.98fps |
| Network protocol | |
| Network protocol | IPV4, TCP, UDP, HTTP, FTP, NTP,DNS, DHCP,ARP, RTSP, RTP,RTCP, RTMP,NDI,SRT |
| Application programming | Supports VISCA, VISCA Over IP, standard protocols (ONVIF), private SDK and third-party management platform access. |
| Number of simultaneous previews | Maximum 20 channels |
| Interface | |
| Multiple video outputs | Support 3-CH HD video output simultaneously (HDMI USB3.0 IP) |
| Network | 1 RJ45, 10M/100M adaptive Ethernet port |
| Communications interface | 1 RS485/232 Compatible Interface, 1 RS232 In, 8-pin DIN |
| General | |
| Menus | English/Chinese Simplified |
| Address range | 0-255 |
| Temperature | Operating temperature: 0ºC~+50ºC, Storage temperature: -20ºC~+70ºC |
| Environmental humidity | 0 - 95% (non-condensing) |
| Power supply | 12V DC |
| Power consumption | <10W |
| Sizes | 142*125*157 mm |
| Net weight | 1.48Kg |
