Chocolate Machine Supplier Chocolate Bar Maker Double Shots Chocolate Moulding Plant Chocolate Production Line with Ce ISO9001 (QJ175)

Product Description

=Automatic double shots Chocolate Moulding Line(Capacity: 150 kgs/h 20hours x150Kgs/h=3000 Kgs/day)
The processing line can continuously produce various kinds of chocolate products. It is an electronic controlled plant which consists of process steps of mould heating, depositing, vibrating, cooling, de-moulding and etc...It can produce out good quality chocolate products such as "two color", " central filling", chocolate and Pure chocolate products.
photos in our customers' plant:
samples of this process line:

Model	QJ150	QJ175
Production capacity ( tons/shift)	1.8~3.2 tons	1.8~3.2Tons
Max. of the central-filling ( %)	30	30
Speed ( n/min)	25~30 moulds/min	25~30moulds/min
Product available	Pure, center-filled chocolate	Pure, center-filled, and double layered chocolate
Vibrating time (length of the vibrating stage)	10~15s (1.5meter)	10~15s (1.5meter)
Cooling time	12~23min	12~23min
Cooling temperature	0~5C	0~5C
Empty moulds heating time (length of the mould heating stage)	10~15s (1.6M)	10~15s (1.6M)
Mould cooling time	3~5s	3~5s
Total power	25KW	32kw
Moulds size and numbers needed	300x225x30mm 240pieces needed	300x225x30mm 360pcs needed
Compressed air consumption Compressed air pressure	2m3/min 0.4~0.8Mpa	2m3/min 0.4~0.8Mpa
Conditions needed for the cooling system: 1. Room temperature(C) 2. Humidity (%)	20~25 55	20~25 55
Dimension(LxWxH mm)	15000 x1050 x2150	17000x1050x2150
Gross weight (Kgs)	5500	6500

---
