US$24,000.00-29,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Harvest method
Cut, Pickup Thresh, Discharge
Portable Harvester Type
Self-Propelled Rubber Track Full Feed
Certification
ISO9001:2008, CE
Application Field
Agriculture
Transport Package
Nude Packing
Production Capacity
10000
Product Description
Feature:
1.Double Threshing Cylinder Combine Harvester.
2.Euiqpped with 125Hp engine, 150hp engine optional. Fuel Tank 140L meet the whole day's work.
3.Big Gear Box ZKB85 and large HST workflow 45CC.
4.Rubber Track 550/600*90*56 enures machine work smoothly in deep mud field.
5.Cutting Width reaches 3.9m, which is mainly used for big farmland.
6.Grain Tank capacity is 2.3m3
Parameters as below
| Model | 4LZ-5.5A | 4LZ-6.0A |
| Type | Self-propelled Whole-feeding | Self-propelled Whole-feeding |
| Dimension (Operation) | Length(mm) | 5400 | 5630 |
| Width(mm) | 4760 | 5050 |
| Height(mm) | 2960 | 3300 |
| Weight(kg) | 3700 | 4250 |
| Engine | Type | In-line, inter-cool, turbo charged diesel engine |
| Power(HP) | 125 | 150 |
| RPM(r/min) | 2600 | 2300 |
| Fuel tank(L) | 150 |
| Gear Box Model | WORLD 85 | WORLD 85 |
| Chassis | Track(mm) | 550/600*90*56 |
| Track Center(mm) | 1450 |
| Min.Ground Clearance(mm) | 290 | 290 |
| Harvesting | Cutting Width(mm) | 3200 | 3900 |
| Feeding volume (kg/s) | 5.5 | 6.0 |
| Header Lifting | Hydraulic |
| Threshing | Type | Two threshing cylinder |
| Cylinder size 1st | ∮650*1155 | ∮700*1355 |
| Cylinder size 2nd | ∮430*1435 | ∮548*1665 |
| Separating Type | Centrifugal blower+vibrating sieves |
| Grain tank | Size(m³) | 2.2 | 2.3 |
| Grain unloading type | Automatic horizontal unloading pipe |
| Operation efficiency(ha./h) | 0.6-1.0 | 0.7-1.5 |
| Crops | Rice, Wheat, barley, Rapessed |
>>
