15 Ton Wheeled Excavator Xe155wga Medium Hydraulic Wheeled Excavator with Sapre Parts Low Price for Sale

Product Description

Product Description
20 Ton Construction Machinery Wheel Digging Excavator Xe155wga with Hydraulic System

*The Customized low-speed and high-torque engine, precise matching of hydraulic system, high operating accuracy, good movement coordination, fuel tank volume increased by 10%, and longer battery life; The cab is newly upgraded with good visibility. The cab layout conforms to the ergonomic layout to minimize driving fatigue. It is equipped with sunshades, rearview mirrors, and a liftable armrest box design, making it easier to get in and out of the car; Added one-button start, Bluetooth phone,high-definition touch instrument, smooth operation, clear vehicle information, high-power heating and cooling air conditioner,three-dimensional surround air outlet, 20% increase in cooling capacity, standard turntable lamp, boom lamp, cab dome light ,working/driving at night is safer.
* XE155WGA Small Crawler Excavator is suitable for earth and stone construction projects such as municipal construction, highway bridges, housing construction, road engineering, farmland water conservancy construction, port construction and so on, it has features of goodflexibility and maneuverability, low fuel consumption, high construction efficiency, large digging force, comfortable drivingenvironment and wide range of application.
* Environmental·Energy-saving·Large power engine New generation environmental engine is adopted in this machine, which has both excellent environmental performance and large power, matched with ow fuel consumption design, operating costs are significantly reduced, and fuel consumption is reduced by 10% or less compared to previous generation of machine. Product Parameters

Model			Unit	XE155WGA
Operating weight			Kg	14200
Bucket capacity			m³	0.58
Engine	Model		/	F4.5CS4145
	/ Rated power/speed		kw/rpm	108/2200
	/ Maximum torque/speed		N.m/rpm	600 /1200
	Piston displacement		L	4.5
Main performance	(/) Travel speed(H/L)		km/h	37/11
	Swing speed		r/min	12
	Gradeability		°	≤35
	Ground pressure		kPa	/
	Bucket digging force		kN	100
	Arm digging force		kN	80
	Maximum tractive force		kN	82
Hydraulic system	Main pump		/	2 piston pump
	Relief valve setting pressure		L/min	2×160
	Pressure of prime valve		bar	34.3×106
	Travel system pressure		bar	34.3×106
	Swing system pressure		bar	25×106
	Pilot system pressure		bar	3.9×106
Oil Capacity	Fuel tank capacity		L	250
	Hydraulic tank capacity		L	135
	Engine oil capacity		L	11
Appearance size		Overall length	mm	7705
		Overall width	mm	2550
		Overall height	mm	3200
		Counterweight clearance	mm	1252
		Minimum ground clearance	mm	380
		Minimum tail swing radius	mm	2300
			mm	6500
		Wheel base	mm	2800
		Tread width	mm	290*2
		Width of platform	mm	2490
		The distance from front axle to the rotary center	mm	1700
		Engine hood height	mm	2560
Working scope		Maximum digging reach	mm	7780
		Maximum ground digging radius	mm	7550
		Maximum digging height	mm	8210
		Maximum dumping height	mm	5875
		Maximum digging depth	mm	4620
		8Maximum depth cut for 8 ft level bottom	mm	4315
		Maximum vertical wall digging depth	mm	4135
		Maximum dozer lifting height	mm	534
		Maximum dozer cutting depth	mm	120
Worker	Standard	Length of boom	mm	4600
		Length of arm	mm	2100
		Bucket capacity	m³	0.58
	Optional	Length of boom	mm	/
		Length of arm	mm	2500
		Bucket capacity	m³	0.26

Detailed Photos
