Anon Ridging Plough Deep Potato Ridger Furrow Plough for Tractor

US$300.00-1,500.00 1 Set (MOQ)

Basic Info.

Model NO.
AN3QL-3
Power Source
Tractor
Operation
Soil Preparation Machinery, Continuous Running Operation
Traction Type
Traction
Drive Type
Gear Drive
Arbor Configuration
Vertical Shaft
Certification
CE
Color
Red
Model
An3ql-3
Working Width
2500mm
Ridging Height
200-250mm
Ridging Spacing
700-900mm
Matched Power
40HP
Weight
3400kgs
Linkage
Standard Three-Point Mounted
Material
Steel
Disc
2PCS, 3PCS,4PCS....
Transport Package
Iron Box
Specification
700X200mm
Trademark
ANON
Origin
Hubei
HS Code
8432100000
Production Capacity
5000sets/Month

Product Description



Ridge plough
Adjustable ridge plough is suitable for the ridging after the plowing, It can match the tractor, the structure is simple, the height and width of the ridging can be adjusted. The frame is consisted of square steel pipe, Ridge disk device can adjust the angle of the ridging, the material of the disc is superior 65Mn, The products are made of heat-treatment processing. It has the reasonable structure, rugged, transportation convenience, easy to be adjusted.
Model
 Unit
 AN3QL-3
 AN3QL-4
 AN3QL-5
Working width
 mm
 2500
 3200
 3900
Ridging spacing(adjustable)
 mm
 700~900
 700~900
 700~900
Ridging height
 mm
 200~250
 200~250
 200~250
Matched power
 hp
 40
 60
 80
