China Popular Automatic Feeding Strong Bench Drilling Machine (Z4032G)

Product Description

Product Description
Automatic feeding Strong Bench Drilling Machine (Z4032G)
Features:
1.Worktable can rise and down by rack/handle, 360° rotation, easy to operate and mechanical advantage.
2.Multi-functional, can use for drilling and tapping.
3.Belt adjust mechanism(by handle), easy and efficient.
4.Long spindle travel, wide machining range.
5.Spindle head, worktable, column and base use high quality casting processed by aging treatment, stability and durable in use.
6.Spindle, spline sleeve, gear shaft processed by heat treatment and hardened.
7.Reasonable structure, high rigidity, high strength.
8.With LED light, whole steel feeding handle, thicken base, more tronger.
9.These optional accessories can be ordered:
belt cover with door limit switch, multi-spindle attachment, DRO, Higher column etc.


Product Parameters
Specification:

MODEL	Z4016G	Z4020G	Z4032G
Max. drilling capacity (in MS)	16mm	20mm	32mm
Max. tapping capacity (In MS)	M10	M16	M24
Column Diameter:	70mm	85mm	100mm
Spindle travel	100mm	135mm	150mm
Distance from spindle to column	193mm	260mm	265mm
Distance from spindle to worktable	330mm	366mm	390mm
Distance from spindle to base	613mm	678mm	745mm
Spindle taper	MT2	MT2	MT3
No. of Speeds , (RPM Range)	5 , (480~4100)	5 , (280~1875)	5 , (280~1875)
Table size	265mm x 285mm	300mm x 320mm	380mm x 400mm
Base Size:	360mm x 480mm	376mm x 566mm	645mm x 470mm
Overall height	1130mm	1245mm	1370mm
Motor power	0.75KW (4 poles)	0.75KW (6 poles)	1.1KW (6 poles)
uni-techmachinery.en.made-in-china.com weight	131,50kg	179kg	230kg
Packing size	850x540x1282mm	990x564x1402mm	1039x644x1512mm

Standard accessories:
--Drill chuck
--Chuck arbor
--Tool dismounting spanner
--Belt
--U-type chuck safety guard
--LED work light
--Steel material feed handle
Optional accessories:
--Vice
--DRO
--Higher column
--Auto-feeding
--Multi-spindles
Detailed Photos

Packaging & Shipping

---
