7.5kw High Shear Mixer Inline Mixer (high shear inline mixer)

Product Description

In-line shear mixer / emulsifying pump / homogenizing pump emulsifier production description
In-line High Shear Mixer is also called as high shear pump, shear pump, emulsifying pump and high shear emulsify pump. It is consist of one set of precisely engineered stator and rotor inside the shear pump chamber. The strong centrifugal forces generated by the high speed rotor absorb the liquid materials such as tomato sauce, syrup and slurry into the working chamber of the rotor and stator from axial direction. Tomato sauce, syrup will be dispersed, sheared and emulsified by the multi-layers Stator & Rotor and then send out of the shear pump.
Optional device for the high shear mixer
In some factory for food and beverage, for example, tomato sauce production factory, several emulsifying pump will be needed in different processing stage. But not all of the pumps are being used in the same time. Thus, we can use the same pump in different processing stage---so, movable base for shear pump will be needed. Under request, we will offer castors for the high shear pumps.
Hopper for movable shear pump is also optional.
Parameter for in-line shear mixer

Model	ILM-1-140	ILM-1-165	ILM-1-180
Motor Power Kw	5.5	7.5	11
Rotation speed rpm	2900	2900	2900
Flow rate m³/h	0~5	0~8	0~12
FOB Ningbo price usd
Installation Dimension in mm
L2	80	80	92
L	660	700	847
H	490	490	554
A	340	340	382
H2	222	222	260
H3	152.5	152.5	167.5
D Φ	63.5	63.5	63.5
B Φ	21	51	63.5

In-line shear mixer
The price you see in this web may not the right price for the high shear mixer you need. If you are in need of any other
Words in the End
Your feedback on our in-line shear pump is more than important to us.
Please be noted that we aim to provide exceptional service and care to every customer we work with, and we truly appreciate you taking the time to tell us about your idea on the shear pump that you need. Also, if you can feedback to us your comment and idea on the offered emulsifying pump, we will highly appreciate it.
High shear emulsifying pump inline shear pump On line service
We are ready to answer your call and questions anytime.
