Product Details
Product Description
Product Description
Features
◆New humanized design
Adopts self-developed external humidification technology with high precision and reliable operation.
Adopt imported fluorine-free compressor, which has long service life, energy saving and environmental protection.
The studio adopts integrated molding technology, with seamless arc transition at all corners, which is easy to clean and is not suitable for breeding bacteria.
The partition is made of high-quality 304 stainless steel rod, which has a large load capacity, and adopts a new design, which can be quickly disassembled and assembled without tools; it is easy to sterilize and clean the studio;
It adopts compound door design, and the inner door is glass door, which is convenient for users to observe the experimental situation in real time.
The working room is equipped with a power socket, and is equipped with lighting and germicidal lamps, which is convenient for lighting and sterilization in the working room.
The operation interface adopts a large-screen LCD screen design, and all functional parameters are displayed on the same screen. Combined with the humanized touch button design, the control is more clear and intuitive.
It has the function of stepless adjustment of circulating air volume.
The dust-proof filter design of the refrigeration system is convenient for cleaning and dust removal.
◆ Intelligent control technology
PID control mode, precise temperature and humidity control with small fluctuation, menu-type operation page, simple and easy to understand and easy to operate.
The parameters set by the user can be automatically saved in the event of a power failure, and the original setting program will run after the power is turned on.
◆ Intelligent multi-stage programmable control
1-30 sections of program can be preset to run, and can be run repeatedly for 0-99 cycles (when the cycle is set to 0, it will work continuously).
Program controls temperature, humidity, time and speed, and can be controlled by multi-step ladder program, which simplifies the complex test process and truly realizes automatic control and operation.
◆ Fault self-diagnosis function
When the equipment fails, the LCD screen will display the fault information, and the operation faults will be clear at a glance.
◆ Security function
Independent temperature limit alarm system, which can prompt the operator to ensure safe operation without accidents.
Abnormal temperature (high or low) alarm.
The device comes with a leakage protector switch.
With water shortage alarm prompt function.
◆ Optional function
RS485 or USB interface and software.
Realize data recording, data communication, graphic dynamic display, fault analysis.
Optional printer system for data recording, in line with GMP standards.
Wireless communication alarm system (SMS alarm system). If the user of the equipment is not on site, when the equipment fails, the system will collect the fault signal in time, and send it to the mobile phone of the designated recipient through SMS as soon as possible to ensure timely troubleshooting, resume the test, and avoid accidental losses.
Ordering information
Model
| PYWS-100A
| PYWS-150A
| PYWS-250A
| PYWS-350A
|
Studio volume (L)
| 110
| 150
| 250
| 350
|
control method
| PID Microprocessor
|
Temperature control range (℃)
| 0-60
|
Temperature Resolution (℃)
| 0.1
|
Temperature uniformity (℃)
| ±1
|
Temperature fluctuation (°C)
| Balanced operation ±0.2 Intermittent operation ±0.5
|
Humidity control range
| 30%-90%RH
|
Humidity deviation
| ±3%RH
|
Programmable function
| Temperature, humidity, 30-segment programs can be set, each setting time range is 1-99 hours
|
Load tray (standard)
| 2pcs
| 3pcs
|
input power
| 800W
| 1000W
| 1500W
| 2000W
|
power supply
| AC220V 50HZ
|
Working temperature
| ＋5-35℃
|
Continuous operation time
| Can run continuously for a long time
|
Studio size (mm)
| 500X400X550
| 500X400X750
| 550X550X850
| 550X550X1140
|
Dimensions (mm)
| 640X668X1210
| 640X668X1410
| 690X820X1510
| 690X820X1800
|
Note: 1. The above performance parameters are measured under no-load conditions: the ambient temperature is 20°C and the ambient humidity is 50%RH;
>>
