Full Automatic PE Film Blowing Machine with Rotary Die Head and Double Winder

US$8,000.00-12,500.00 1 Set (MOQ)

Basic Info.

Model NO.
SJ-700
Raw Material
PE
Maximum Folding Width of Film
600mm
Screw Diameter
65mm
Automation
Automatic
Computerized
Non-Computerized
Machine Weight
3t
Certification
CE, ISO9001:2008
Motor Brand
Siemens Brand
Power
18.5kw
Film Thickness
0.005-0.08mm
Material
HDPE LDPE LLDPE
Application
for Making Plastic Bag Film
Die Head
2 Die Head, Double Die Head
Scew No.
1 Screw
Transport Package
Wooden or as Required
Specification
CE, ISO9001, SGS
Trademark
NuoSheng
Origin
China(Mainland)
HS Code
84773090
Production Capacity
60kg/H

Product Description


this machine is design for plastic bag production line.
this mahcine is with bigger size screw and with 2 die head to inprove the production capacity .
thus the bag making speed will be much quick to assure the customer profit.
Specificate:
Type: SLB-700
Diameter of Screw : 65 mm
Screw L/D Ratio : 28:1 or 30:1
Film-blowing Width: 100-600MM
Film-blowing Thickness: :LDPE0.015-0.20 HDPE0.008-0.05mm
Output: 60 kg/h
Total Power: 30kw
Overall Dimensions(L×W×H)mm: 5000×2500×4200
Total Weight: 3500kg
the extruder part with 1 screw but with 2 die
Product Description
Model SJ-A45 SJ-A50
SJ-A55 		SJ-A60 SJ- A65
Suitable material HDPE LDPE LLDPE
Film width(mm) 100-500 300-600 400-800 500-1000 600-1200
Film thickness(mm) HD 0.009-0.05 0.009-0.15
LD 0.02-0.15 0.03-0.15
Max.Extrusion output(kg/hr) HD 40 45 55 60 65
LD 45 50 60 65 70
Extruder
Screw diameter(mm) φ45 ф50 ф55 Ф60 ф65
Screw L/D length 28:1/30:1
Screw material SACM-645/38CRMOALA
Cylinder material SACM-645/38CRMOALA
Cylinder cooling 180x2 250x2 370x2 370x2 550x2
Driving motor (kw) 7.5 11 15 18.5 22
Temperature control 3 3 3 3 4
Average power-consume(kw) 10 12 18 22 30
Type of die
Die size HD ф60/80 ф80/100 ф100/120 ф100/120 ф100/150
LD ф100/120 ф120/150 ф180/200 Ф200/220 ф220/ 250
Temperature control 3
Air ring 1
Air blower(kw) 1.5 2.2 3 3 4
Center steady stick 1
Take-up unit
Roller width(mm) ф165×600 ф165×700 ф165×900 ф165×1100 ф165×1300
Height adjustable type 800mm
Take-up speed(m/min) 10-100 10-100 10-80 10-80 10-80
Take-up motor(kw) 0.75 1.1 1.1 1.1 1.5
Winding unit
Type Surface friction type
Winding motor(N.m) 10 10 10 16 16
Winding speed(m/min) 10-100 10-100 10-80 10-80 10-80
Cover dimension(m) 5.0×2.0×4.1 5.0×2.2×4.5 5.5×2.5×5.2 5.6×2.8×6.0 5.8×2.8×6.3

machine picture :
