EV48-40 3.0 HUADA HAWKER AGV BATTERY 48V40Ah
Huada Hawkerer Lithium Battery EV Series
Huada Hawkerer 24V,48V lithium iron phosphate batteries
Nominal voltage:24V/48V nominal capacity:20-200AH operating temperature:charging 0-45℃,discharging-20-60℃Application areas:AGV,mobile robots,industrial machinery and equipment,emergency power supply,etc
Ordering model nominal voltage(V)capacity(Ah)size
(mm)Weight
(Kg)
EV48-40 3.0 HUADA HAWKER AGV BATTERY 48V40Ah
Huada Hawker EV24-30 25.6V 30 390*199*130 9
Huada Hawker EV24-40 1.0 25.6V 40 315*237*165 17.5
Huada Hawker EV24-40 2.0 25.6V 40 527*155*170 17.5
Huada Hawker EV24-60 1.0 25.6 60 333*241*214 25
Huada Hawker EV24-60 2.0 25.6 60 325*237*187 25
Huada Hawker EV24-80 25.6 80 356*335*216 29
Huada Hawker EV24-100 25.6 100 356*335*216 34
Huada Hawker EV24-120 25.6 120 400*275*248 41.5
Huada Hawker EV24-200 25.6 200 551*210*433 65
Huada Hawker EV48-20 48 20 315*237*165 17.5
Huada Hawker EV48-30 48 30 380*238*202 21.4
Huada Hawker EV48-40 48 40 356*335*216 32
Huada Hawker EV48-50 48 50 788*170*170 36
Huada Hawker EV48-60 1.0 48 60 567*241*226 40
Huada Hawker EV48-60 2.0 48 60 430*350*216 40
Huada Hawker EV48-100 48 100 614*346*202 65
Huada Hawker EV48-160 48 160 606*456*255 86.5
Huada Hawker EV48-180 48 180 600*275*517 95
Huada Hawker EV48-200 48 200 700*555*294 130
Huada Hawkerer battery specifications can be customized.For more information,please contact Huada Hawkerer Battery's Wang Zelong.
Huada Hawkerer Battery Type:Lithium Iron Phosphate Battery
Maximum charging current:2C
Maximum discharge current:2C
Instantaneous discharge current:3C
Discharge cut-off voltage:23.6V/43.5V
Charging temperature:0-45℃
Discharge temperature:-20~60℃
Storage temperature:-20~60℃
Temperature protection:65℃±5℃
Battery casing:Sheet metal casing
Port Design:Different Ports
Lithium battery protection:short circuit protection,overcharge protection,overdischarge protection,overcurrent protection,temperature protection,etc
Communication interfaces:485,CANOPEN,CAN,AO(0-5V represents 0-100%),DO(2 channels),DI,etc
Application areas:AGV,mobile robots,industrial machinery and equipment,emergency power supply,etc
Product Features
Fast charging:Supports 2C fast charging,and can be fully charged in up to half an hour.
Dumb plug:Using different plug specifications for charging and discharging can avoid incorrect insertion.
Port design:Charging and discharging port design,supporting simultaneous charging and discharging without disturbing each other.
Self developed BMS:
A battery management system for mobile robots with rich communication interfaces.
It can achieve the function of recording,storing,and exporting fault data.
The control system is designed with extremely low power consumption.Shutdown status 30uA,power on status 30mA
Support customization of various non-standard functions.
Environmentally friendly and long-lasting:using automotive grade power lithium iron phosphate battery cells with high cycle life,in line with the values of low-carbon,energy-saving,and environmental protection;
Professional design:By filling the shock-absorbing structure inside the cold-rolled sheet metal shell,the requirements of strong heat dissipation,high safety,and high reliability are achieved.
