10 Ton Per Hour Complete Broiler Feed Making Machine

Product Description

Flat die feed pellet machine mainly used for making pellets for their own animals, while ring die poultry feed pelletizer is more efficient and suitable for industrial poultry feed pellets production-large farms or feed pellets factory. The livestock animal feed pellet machine pellitizing corn, oil seed meal/cake, stalk, straw, fish meal, alfalfa, wheat, grass and other maetial into feed pellets, which can be usd for chicken, cattle, horse, dusk, dog, cat, rabit, cow, fish, sheep, goat, geese, pig, deer, birds and ostrich etc. Equipped with conditioner, this pellet mill equipment can make the material fully mixed and ripen, thus the finished feed pellets have more smooth surface and better quality. Featured by high throughput and low consumption, ring die poultry feed pellet machine has enjoyed great popularity.

Model		250C	320B	350B	400B	450B	508B
Feeder power(kw)		0.75	0.75	0.75	1.5	1.5	1.5
Conditioner power(kw)		1.1	2.2	2.2	4	4	5.5
Main motor power(kw)		22	22x2	30x2	45x2	55x2	75x2
Ring die diameter(mm)		250	320	350	400	450	508
Capacity(t/h)		1-2	2-5	3-7	4-10	6-12	8-15
Dimensions (mm)	Single conditioner	1300x650x1750	1800x1800x1650	1800x2000x1850	2300x2000x2200	2350x2300x2100	3350x2350x2200
	Double conditioner	1300x650x2050	1800x1800x2000	2150x2050x2200	2300x2000x2450	2350x2300x2550	3350x2350x2650
Weight(kg)	Single conditioner	700	1580	2200	2780	3280	4200
	Double conditioner	850	1850	2500	3200	3700	4750
Application		For chicken, cattle, horse, dusk, dog, cat, rabit, cow, fish, sheep, goat, geese, pig, deer, birds and ostrich etc
Raw Material		Corn, oil seed meal/cake, stalk, straw, fish meal, alfalfa, wheat, grass, etc.

Working Principle of Ring Die Poultry feed Pelletizer/Pellet Machine
When the ring die pellet mill starts to work, the material from the feed inlet goes into a pre-conditioner, in which other ingredients are added depending on the target product and steam is injected to start the cooking process. When the material temperature is maintained about 64- 84°C and moisture between 14- 1 6%, the material can enter the granulating chamber with high speed rotary and distribute through scraper to ensure feed evenly. Then the material is pressed into a rotating ring die with the help of two press rolls which are free to rotate on their respective shafts. The resulting pressure compresses the material and extrudes it in cylindrical form through the radial holes in the die.At last, the outer-side stationary knives cut the pellets to a pre-set length.
Poultry Livestock Granulator Structure
Raw Material of Feed Pellets
The livestock animal feed pellet machine pellitizing corn, oil seed meal/cake, stalk, straw, fish meal, alfalfa, wheat, grass and other maetial into feed pellets. The feed pellets made by our machine can be usd for chicken, cattle, horse, dusk, dog, cat, rabit, cow, fish, sheep, goat, geese, pig, deer, birds and ostrich etc.
Advantages of Animal Feed Pellet Machine for Livestock/Poultry
Animal Feed Pellet Machine Applications
Animals can have better and improved performance after feeding on pelleted feed compared to the mixed rations. Feed processing machine is designed to make small feed pellets of different types of solid grain.
-Size of Feed Pellets: 2~10 mm
-Application of Animal Feed Pellets: Chicken, Quails, Ducks, Geese and Other Livestock such as Cattle, Pigs, Goat and Rabbits, and etc.
-Raw Materials for Animal Feed Pellet Production: Rice, Corn, Wheat Bran, Beans, Fish Meal, Oil Cake and etc.
Feed pelleting machine is an essential feed processing equipment to make various feed pellets for different animals. The widely used animal feed pellet mill is flat die feed machine and ring die feed machine based on the output.
Our ring die pellet mill is more suitable for medium and large commercial feed processing plant. Small electric animal feed pellets machine is the most widely used in many poultry farms, livestock breeding farms or small scale feed pellet mill plant.
We also make flat die feed mills, which are suitable for household, farm, mini or small scale feed pellet production. It is usually designed with electrical engine, diesel engine, PTO engine and gasoline engine.
Feed Pellets Making Process
1. Material selection: Choose materials and suitable additives that can provide the different nutrients that animals need.
In addition, the content of each material should be strictly controlled, as it directly affects the durability of the particles.
2. Crushing: Crush the materials into powdery materials by feed hammer mill.
3. Mixing: Mix the crushed ingredients evenly by feed mixing machine.
4. Pelletizing: In this step, material modulation and physical condition control are critical to particle quality. Heat, water time and quantity, steam are important factors in granulation. The diameter and die thickness of the feed pellet machine
also affect the quality of the pellets, the relative pellet hardness and the yield of the pellet machine.
5. Cooling: In fact, it is not necessary to make feed pellets at home, as small capacity production allows feed pellets to
cool naturally. But for relatively high productivity, pellet coolers can be very helpful and save farmers a lot of time.
6. Packing: pack the pellets into bags and onto pallets.
Our Certificate
The Client with Us
OUR SERVICPre-sale service
1.Our professional and experienced engineer team helps every client to find his most suitable equipment or chose of plant.
2. Any kind of legal logo printing or design are available.
3.Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you.
After you choose:
1. We will make drawing and show you how the pant looks.
2. Every equipment will be checked carefully before packing. Video on machine testing is available.
3. Email you the tracking no., and help to chase the container until it arrives you.
After-sale service
1.We are very glad that customers give us some suggestion for price and products.
2.If you have any question,please contact us freely by E-mail or Telephone.FAQQ. what is your payment term?
A: T/T 30% down payment, balance to be paid before shipment.
Q: what is your main market?
A: South America, Eastern Europe, Southeast Asia, Africa, Oceania, Eastern Asia
Q: what is your producing time?
A: Producing time depends on that machines you ordered. Usually takes 45 days.
Q: what documents you can offer?
A: We can offer invoice, packing list, contract, instructions, customs declaration, certificate of origin, CE. If client need other documents, specifications, please confirm with service staff.
Q: If equipments have some quality problem, how would you deal with?
A: We will responsible for all the quality problems. We will check the machine to get the problem. If need parts, will send them to you.
Q: how to install the equipments?
A: We send 1-2 engineer (100usd/person/day) to the local plant for helping install and commissioning equipments. To save time, our service stuff will tell you what to prepare in advance. We can also teach the workers to how to use the machines and how to make the products better.

---
