| Maximum turning diameter bed | 210mm |
| Maximum turning diameter of middle carriage | 140mm |
| Two top distance | 400mm |
| Spindle speed range/Grade | 50-2250rpm/variable |
| Taper of spindle bore | MT3 |
| Spindle bore | 22mm |
| Tailstock quill travel | 60mm |
| Taper of tailstock quill | MT2 |
| Cross slide travel | 75mm |
| Top slide travel | 55mm |
| Range of metric threads | 0.3-3mm |
| Range of inch threads | 10-44T.P.I |
| Cutting feeds | 0.089/0.147/0.198mm |
| Noise | <75dB |
| Motor | 220v/750w 50HZ |
| N.W./G.W. | 60/75kg |
| Machine size | 823×398×340mm |
| Packing size | 900×480×480mm |
