Tool Grinding Machine Mr-U3 Mr-X1 Mr-X3 Mr-X3a Mr-X5 Mr-X6a

Product Description

Universal Drill Grinder MR-U3It is specially designed for sharpening various diameters,shapes,angles of carving knives,round knives,straight shank cutter,end
mill,drill,lathe tool,engraving cutter and so on;
it is with good precision,competive price,on skill request.
Product Description
1.For grinding HSS and carbide engraving cutter as well as single lip or multiple lip cutters of various shapes such as radiuses
cutters or negative taper angle of cutters. 2. The universal index head is provided at 24 positions so that any particular angle of shape can be obtained, free 360 or 100
rotation is allowed for grinding End Mills,Twist Drill,Lathe Tools, only replace the attachment to the index head without any complex
setup.

Model	MR-U3
Max. collet capacity	Φ18 mm
Max. grinding dia.	Φ18 mm
Longitudinal traver of index head carrier	140mm
Longitudinal adjustment trave of index head carrier	180mm
Spindle and wheel longltudinal adjustment travel	600mm
Taper angle range	0~ 180 (degree)
Relief angle range	0~ 45 (degree)
Negative angle range	0~ 25 (degree)
Motor	1/3HP 220V/380V 50HZ
Grinding spindle	5300rpm
Grinding wheel	Φ100×50×Φ20
Dimension	55×46×49cm
Weight	55KG
Standard Equipment	5 collets: Φ4, Φ 6, Φ 8, Φ 10, Φ 12
	Pin grinding Wheel ×1
	Belt×1
	Diamond pen×1
	Twist drill grinding attachment×1
	End mill grinding attachment×1
	Lathe tools grinding attachment×1
Option Equipment	Eleven piece collets: Φ 3, Φ 4, Φ 5, Φ 6, Φ 8, Φ 9, Φ 10, Φ 12, Φ 14, Φ 16, Φ 18

---
