Basic Info.
Recording Quality
Max 96mbs@2160p 60fps
Max Input Resolution
3840*2160@60fps
Max Record Resolution
3840*2160@60fps
Max Onput Resolution
3840*2160@60fps
Transport Package
Carton Box
Specification
60cm*70cm*50cm
Production Capacity
200/Month
Product Description
Product Description
Product Parameters
Power | Voltage | AC 100-240V 3A 50/60Hz, SWITCH POWER SUPPLY |
Connector | 3 prong AC Jack |
Video and Photo | Video Encoder | H.264/AVC |
Resolution | 2160P60@25/30/50/60fps, 1920P1080 @25/30/50/60fps, 1280P720 @50/60fps, Compatible with low resolution |
Bit Rate | Adjustable bitrate; default. 48 Mbits/s, |
Frame Rate | self-adaption |
Codec | H.264, mp4 file format |
Rate Control | CBR/VBR |
Photo | Jpeg, BMP |
Network | LAN | 100/1000M Base-T |
Streaming | RTMP |
Audio | Sampling | 32-48Khz 16bits |
Codec | AAC Stereo |
Channels | 2 x Audio jack |
Interface | HDMI Input | HDMI2.0 x 1 Type A, |
HDMI Loop Out | HDMI2.0 x 1 Type A, |
Audio In | 2CH 2 x 3.5mm, jack 20Kohm higher |
Aduio Out | 2CH, 2 x 3.5mm Jack |
Network | RJ45, 100/1000M Ethernet |
USB | 4 x USB,TYPE A, 2 x front, 4 x rear |
Visible | Color LED |
LCD | 7.0" IPS, Resistance Touch |
Button | Metal dome |
Storage | Internal | 2.5'' SATA SSD |
External | 2 x USB Flash Drive, |
Disk Format | NTFS, exFAT, FAT32 |
*USB 3.0 Flash drive recommended |
Physical | Size | 300 x 211 x 97.5mm(11.8" x 8.3" x 3.8") |
Weight | 2.98kg |
Operating | 0°C to 50°C |
Storage | ~20°C to 60°C |
| Certificate | CE (EN60601-1, EN60601-2) |
