Product Details
Product Description
Product Description
Features
1.Access to LTE seamlessly, wide signal coverage, fast network attachment and high data transfer rate;
2.Support reed, magnetic resistance, Hall, magnetic and other metering methods;
3.Record hourly, daily, monthly and intensive data, with data packet function;
4.Support multiple platform access mode and network protocol, data escalation anomalies can be flexible switching;
5.Control the valve remotely, detect the abnormal valve data and report to the platform;
6.Built-in 5 step water price, support a variety of payment mode, support usage alarm, default valve and other functions;
7.Support magnetic interference, sensor abnormality, leakage, battery undervoltage and other abnormal alarm;
8.Support remote modification of upload cycle, communication IP and other parameters;
9.All devices support remote online upgrades.
Technical Parameter
| Nominal diameter | 15 | 20 | 25 | 32 | 40 |
| Range ratio | R80 | R80 | R80 | R80 | R80 |
| Minimum flow rate Q1 (L/h) | 31 | 50 | 79 | 125 | 200
|
| Boundary flow rate Q2 (L/h) | 50 | 80 | 126 | 200 | 320 |
| Normal flow rate Q3 (L/h) | 2500 | 4000 | 6300 | 10000 | 16000 |
| Overload flow rate Q4 (L/h) | 3125 | 5000 | 7875 | 12500 | 20000 |
| Power supply method | DC3.6V (disposable lithium battery) |
| Accuracy Class | Class 2 |
| Maximum allowable pressure | 1.6MPa |
| Temperature Class | T30/T50/T90 (optional) |
| Environmental Class | Class B |
| Flow field sensitivity Class | U10/D5 |
| Electromagnetic compatibility Class | Class E1 |
| Communication interface | Cat1/Infrared |
| Protection Class | IP68 |
Outline Dimension
| Nominal Diameter | Length L (mm) | Width W (mm) | Height H (mm) | Thread Diameter D (mm) |
| DN15 | 165 | 110 | 137 | G3/4B |
| DN20 | 195 | 110 | 137 | G1B |
| DN25 | 230 | 110 | 137 | G1 1/4B |
>>
