Description:
White fused alumina was made from the high-quality alumina by melting above 2000 in the electric arc furnace and cooling. It is white with the main crystal phase alpha-Al2O3. The white alumina produced in titling electric arc furnaces has the advantage of high bulk density and low porosity and good volume stability and thermal shock resistance. As a most commonly used corundum in the abrasive industry, White fused alumina has a long history in applications because of its high hardness, good self-sharpening advantages. By adopting high-quality grade materials, strict quality control system developed production technology, HAIXU’s white fused alumina get a high purity, stable quality and good distribution.
The micro-powder from Haixu Abrasives are acid-washed and get water pickled, by this process, the white fused alumina powder is with better purity and better grit size distribution.
Characteristic:
The electrofused aluminum oxide powder for polishing has outstanding features including small crystal size, impact resistance. By ensuring the excellent purity, HAIXU Abrasive's product works very extraordinary well at sand blasting and raw material for abrasive tools. Users will get a multi-recycle experience and more durable performance.
TYPICAL CHEMICAL ANALYSIS
|
AL2O3
| ≥99%
|
Fe2O3
| ≤0.10%
|
NA2O
| ≤0.30%
|
TYPICAL PHYSICAL PROPERTIES
|
Hardness:
| Mohs:9.0
|
Maximum service temperature:
| 1900 ℃
|
Melting Point:
| 2250 ℃
|
Specific Gravity:
| 3.95g/cm3
|
Volume density
| 3.6g/cm3
|
Bulk density(LPD):
| 1.55-1.95 g/cm3
|
Color:
| White
|
Particle shape:
| Angular
|
Available size:
|
FEPA
| F230 F240 F280 F320 F360 F400 F500 F600 F800 F1000 F1200 F1500
|
JIS
| 240# 280# 320# 360# 400# 500# 600# 700# 800# 1000# 1200# 1500# 2000# 2500# 3000# 4000# 6000# 8000# 10000#
|
FEPA-microgrits sizes
|
Grit designation
| Mean grain size ds50-value in μm
|
F 230
| 53.0 ± 3
|
F 240
| 44.5 ± 2
|
F 280
| 36.5 ± 1.5
|
F 320
| 29.2 ± 1.5
|
F 360
| 22.8 ± 1.5
|
F 400
| 17.3 ± 1
|
F 500
| 12.8 ± 1
|
F 600
| 9.3 ± 1
|
F 800
| 6.5 ± 1
|
F 1000
| 4.5 ± 0.8
|
F 1200
| 3.0 ± 0.5
|
F 1500
| 2.0 ± 0.4
|
F 2000
| 1.2 ± 0.3
|
JIS Grit Size
| D0(Micron)
| D3(Micron)
| D50(Micron)
| D94(Micron)
|
#240
| ≤ 127
| ≤ 103
| 57.0±3.0
| ≥ 40
|
#280
| ≤ 112
| ≤ 87
| 48.0±3.0
| ≥ 33
|
#320
| ≤ 98
| ≤ 74
| 40.0±2.5
| ≥ 27
|
#360
| ≤ 86
| ≤ 66
| 35.0±2.0
| ≥ 23
|
#400
| ≤ 75
| ≤ 58
| 30.0±2.0
| ≥ 20
|
#500
| ≤ 63
| ≤ 50
| 25.0±2.0
| ≥ 16
|
#600
| ≤ 53
| ≤ 41
| 20.0±1.5
| ≥ 13
|
#700
| ≤ 45
| ≤ 37
| 17.0±1.5
| ≥ 11
|
#800
| ≤ 38
| ≤ 31
| 14.0±1.0
| ≥ 9.0
|
#1000
| ≤ 32
| ≤ 27
| 11.5.±1.0
| ≥ 7.0
|
#1200
| ≤ 27
| ≤ 23
| 9.5±0.8
| ≥ 5.5
|
#1500
| ≤ 23
| ≤ 20
| 8.0±0.6
| ≥ 4.5
|
#2000
| ≤ 19
| ≤ 17
| 6.7±0.6
| ≥ 4.0
|
#2500
| ≤ 16
| ≤ 14
| 5.5±0.5
| ≥ 3.0
|
#3000
| ≤ 13
| ≤ 11
| 4.0±0.5
| ≥ 2.0
|
#4000
| ≤ 11
| ≤ 8.0
| 3.0±0.4
| ≥ 1.8
|
#6000
| ≤ 8.0
| ≤ 5.0
| 2.0±0.4
| ≥ 0.8
|
#8000
| ≤ 6.0
| ≤ 3.5
| 1.2±0.3
| ≥ 0.6
|
Application:
Surface treatment/finishing.
Lapping, polishing, decorative non-skid tile, and pressure blasting.
Ceramic tiles special ceramics.
Additives in epoxy floor painting, special coating.
The ideal raw material for oilstone, sharpening stone, whetstone, and other lapping tools.
Anti-friction material, anti-resisting grounds/paper/painting.
Ceramic water filter material such as filter plate and ceramic membrane tube.
Wear resistance coating, laminates.
Used for making polishing paste/solution etc.
>>
