| US$12,500.00-22,500.00 | 1 Piece (MOQ) |
| TECHNICAL PARAMETERS | ||
| Item | Specifications | Optional parts |
| reed space | Nominal reed space :190,210,230,250,280,340,360cm | |
| Yarn range | 2-Nozzle,4-Nozzle,6-Nozzle for free choice | |
| Drive | Direct control and positioning stop through electromagnetic brake | |
| Push-button bimanual operation and forward-reverse inching motion | | |
| Ultra start motor 3.0KW (Cam shedding)3.7KW(Dobby shedding) 6.5KW (Jacquard shedding) | | |
| Weft insertion | Main nozzle and sub-nozzle combined type | Stretch nozzle |
| Adopt profile reed | | |
| Auxiliary main nozzle | | |
| shedding | Positive cam shedding: Heald Frames max.8 pcs | |
| Dobby shedding: Heald Frame max.16pcs | | |
| Jacquard shedding | | |
| Let-off | Positive easing,double back girder | |
| Single warp beam (below 280cm) | Twin-beam | |
| Positive easing,double back girder | | |
| Flange dia: 800 | 914;1000 | |
| Take up | Electronic take-up | Mechanical winding |
| Pick density range:25~205pcs/inch(mechanical take-up),25~300pcs/inch (electronic take-up) | | |
| Length counter:display of weaving reports, with fixed-length stop function | | |
| Max. Take-up dia.: φ600mm(cam, dobby,jacquard shedding); φ520mm (crank shedding) | | |
| Temple:top-mounted type. | | |
| Beating-up | Crank type multiple sley sword beating-up mechanism | |
| 4-Link rod beating-up(190~280om),6-Link rod beating-up (above 280cm) | | |
| Measuring/storing | Vibrating type pick storer | |
| Weftstand | Floor-mounted 4 cones (2-nozzle);floor-mounted 8 cones(4-nozzle | |
| Selvedge | Planetary gear motion | |
| Waste filling removal | Catch cord type | |
| Cutter | Mechanical type | |
| Lubrication | Oil bath system for the main driving parts,centralized lubrication by manual | Automatic centralized lubrication |
| Auto-stop motion | Weft yarn:photoelectric weft feeler, double feelers | |
| Warp yarn: electric contact-type 6-row droppers | | |
| Others: stop motion for selvedge and calch cord yarn | | |
| Stop cause indication: information display on toluch screen, multiple function 4-color lamp display | | |
| Automation | Artificial intelligent touch screen:with functions of parameter setting, Auto control, automatic monitoring, self-diagnosis. | |
| Pick finding device: automatic shed finding | | |
| Slow inching by inverter(forward,reverse) | | |
| USB data interface | ||
