Heavy-Duty Geared Trolley for Industrial Lifting and Moving

Negotiable 1 Piece (MOQ)

Basic Info.

Model NO.

CSL-Y4

Application

Double Beam Crane, Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane

Type

Electric Hoist

Sling Type

Wire Rope

Lift Speed

2~8m/min

Maximum Lifting Height

>20m

Certification

ISO9001:2000

Condition

New

Color

Orange

Packaging Details

Carton and Pallet

Supply Ability

10000 Sets Per Yea

Usage

Construction Hoist

Capacity

500kg to 5000kg

Transport Package

Wooden Case

Specification

0.25T-10T

Trademark

SEAGULL/OEM

Origin

China

HS Code

84251100

Production Capacity

50000 Units Per Year

Product Description

characteristic:
There are two types of monorail trains: manually operated monorail trains and manually operated monorail trains. The manually operated monorail train is driven by a bracelet, while the manually operated monorail train is driven by lifting heavy objects and can freely walk on the lower flange of the I-beam rail. The distance between the wheel flange can be adjusted according to the width requirements of the I-beam rail. The manual hoist can be hung under the train to form a manual lifting and transportation trolley, which can be used in various lifting machinery and equipment industries.

Hand pulled trolley is a type of lifting machinery that is structurally simple, easy to operate, lightweight, and suitable for transportation. It can be paired with chain hoists, electric hoists, and other lifting products to form a lifting and transportation trolley. It can run freely on the lower flange of an I-beam track with a certain curvature radius, and is used for transporting goods, equipment, etc.

model	load(T)	test load(T)	Specification(mm)				IRecommended beams	net weight(kg)
model	load(T)	test load(T)	A	B	C	H	IRecommended beams	net weight(kg)
0.5	0.5	0.75	208	172	190	108.5	75-125	5.5
1	1	1.5	220	206	222	122	75-125	8
1.5	1.5	2.25	260	231	238.5	130	100-150	13
2	2	3	260	240	267	132.5	100-150	14
3	3	4.5	285	279	319	181	100-150	21
5	5	7.5	338	318	384	219	125-175	35
10	10	15	362	380	490	275	125-180	66
