ZSK4725SFX 3/4/5 CNC sliding table multi-station drilling and tapping machine

Product Description

Product Description
ZSK4725SFX 3/4/5 CNC sliding table multi-station drilling and tapping machine

Model	ZSK4725SFX 3/4/5
Max. Drilling capacity(mm)	25/20
Max. Tapping capacity(mm)	M20/M16
Max.spindle travel(mm)	120
Morse taper of spindle nose	MT.3
Spindle speeds(r/min)	340-570-1000-1800 (Drilling spindle) 230-390-680-1230 (Tapping spindle)
Spindle feed drive way	Serve
Spindle feed speed(mm/min)	W7500
Positioning accuracy(mm)	0.06
Repeatability accuracy	0.03
Two column center distance(mm)	285
Max. slip velocity worktable(mm/min)	W25000
Max. longitudinal travel of worktable(mm)	520
Max. transverse travel of worktable(mm)	180
Distance from spindle axis to column surface(mm)	242.5
Distance from spindle to table(mm)	300-580 (with Y axis 224-504)
Main Motor power(kw)	Drilling: 1.1, tapping: 0.75(6steps)
G.W/N.W(kg)	960(1100,1250)/860(1000,1150)
Ship measurement(cm)	180(180,230)x 115x 180

Company Profile
Customers' Feedback
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don't have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What's the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.

---
