High Productivity Big Harvesting Machine 360HP Self-Propelled Grain Combine Harvester Agricultural Machine

Product Description

Product Parameters

Model		4LZ-18
Horsepower		Yuchai 360HP
Drive type		4WD
Dimension(L*W*H)(mm)		10500*8500*3950
Weight(kg)		15500
Cutting width (mm)		7600-8500
Production efficiency	Productivity(hm²/h)	1.0-3.5
	Fuel tank capacity(L)	600
	Working speed (km/h)	4-10
	Feeding speed(kg/s)	18
Thresher	Grain tank(m³)	11.5
	Max unload height(mm)	4800
	Grain unloading drum height(mm)	5700
	Threshing pattern	Vertical axial flow rod tooth type
	Sorting method	Reciprocating vibrating screen+Centrifugal fan
Chassis	Wheel base(mm)	3845
	F/R wheel space(mm)	F:2800/R:2700
	Tyre model(F/R)	F:800/65R32 R:540/65R28

Detailed Photos
4LZ-18 type self-propelled wheat harvester uses longitudinal axis flow roller separation technology, mainly harvesting wheat, rice.
By replacing parts, it can also harvest soybeans, miscellaneous grains, and corn kernels.


Product Description
More detailed technical information about 4LZ-18
A working width of 7.6-8.5 meters and a feeding rate of 18 kg/s; A Yuchai 360 horsepower engine,the driver can choose different power outputs according to the different crops to be harvested, saving energy and fuel; All of tyres use enlarged and wide high-pattern tires. They have strong adaptability to sandy, muddy, and slippery land; A sturdy four-wheel drive structure. The front drive uses a static hydraulic drive for comfortable and convenient operation. The 1000 series front axle + heavy-duty four-wheel drive rear axe has strong load-bearing capacity and good roadability; An elongated fish scale screen increases the cleaning area. convenient and quick-change concave screen panels can be used to quickly change the cutting header and threshing components to complete the harvest of wheat, corn, soybeans, sorghum, and other crops, achieving multiple uses with one machine; A heavy-duty high-low gearbox roller transmission housing, combined with a continuously variable speed disk, allows the roller speed to adaptively adjust from 300 to 1100. All the spherical bearings of the entire vehicle use American Peer bearings, which have strong load-bearing capacity and long service life. The transmission belt uses a black one-tooth belt, which has strong tension and good heat dissipation, meeting the needs of long-time and large area operations; The high-end large-longitudinal axis flow harvester's cutting header bridge has a reverse function, making it easier to clean the bridge and cutting table blockage; The grain tank is raised and lowered automatically with a hydraulic one-button operation. The driver can open and close the grain bin cover through the electric control button. Company Profile
