Popular Horizontal Drictional Drill Xz320A

Product Description

Popular XZ320A Horizontal Drictional Drill For Sale
Specifications
XZ320A Horizontal Drictional Drill
Dongfeng Cummins (170KW) engine
Backreaming diameter: 800 mm
XZ320A Horizontal Drictional Drill
Technical Features of XZ320A:
Push/pull type: It adopts motor-chain structure, which improves stability.
Rubber track: The rubber track has minor influence on the road, lawn, and scenic spot.
Rotatable control panel: It widens the field of view and reduces operator fatigue.
Reasonable system match: The rotation, push/ pull of power head, and the slurry pump are driven by different hydraulic pumps, which do not interfere with each other. And the hydraulic pumps, valves and pipelines are reasonably matched, featuring small energy loss.
High speed power head: The high speed power head ensures high work efficiency without compromising the rotary torque and the push/pull force during pipe laying operation.
Wide Application: The engine features turbocharged torque increment function, which can increase power instantaneously when encountering tough geological conditions, which ensures drilling power. Items Unit Parameters

Engine	Make		Dongfeng Cummins
	Model		6CTA8.3-C240
	Rated power	kW/ rpm	179/2200
Push/pull force	Type		2-motor rack type
	Max. pull/push force	kN	400/400
	Power head rotary speed	m/min	0~22
Slewing	Type		Motor drive gear transmission
	Max. torque of power head	N.m	14000
	Power head rotary speed	r/min	0~100
Drill stem	Type		Standard API drill stem
	Diameter	mm	φ83
	Length (single)	m	3
Drill mounting	Type		Box type
	Adjustment angle	°	10~22
Travel drive	Type		Self-propelled steel track
	Travel speed	km/h	2.8
Slurry pump	Type		Hydraulic drive
	Flow	L/min	450
Dimension		mm	7000x2170x2450
Weight		t	12

---
