| Factory Model No. | UHP033CS32 | UHP056CS32 | UHP072CS32 | UHP094CS32 | UHP120CS32 | UHP140CS32 | UHP170CS32 | |
| Heating capacity | kW | 3.34 | 5.56 | 7.24 | 9.43 | 11.7 | 13.6 | 16.8 |
| Power consumption | kW | 0.68 | 1.09 | 1.45 | 1.85 | 2.3 | 2.72 | 3.36 |
| C.O.P. | W/W | 5.0 | 5.0 | 5.0 | 5.1 | 5.1 | 5.0 | 5.0 |
| Heating capacity | kW | 2.32 | 3.67 | 4.73 | 6.65 | 8.04 | 9.27 | 11.45 |
| Power consumption | kW | 0.58 | 0.90 | 1.15 | 1.58 | 1.91 | 2.21 | 2.79 |
| C.O.P. | W/W | 4.0 | 4.1 | 4.1 | 4.2 | 4.2 | 4.2 | 4.1 |
| Compressor type | Rotary type with R32 refrigerant, GMCC or the similar class brand. | |||||||
| Voltage | 220-240V~50Hz/1PH | 220-240V~50Hz/1PH | ||||||
| Rated Current | A | 3.0 | 4.8 | 8.1 | 9.9 | 11.2 | 14.0 | 14.5 |
| Max. Current | A | 5.5 | 7 | 10 | 14 | 17 | 19 | 24 |
| Advised pool volume (covered) | m³ | 0-10 | 10-16 | 15-26 | 25-32 | 30-60 | 40-68 | 55-80 |
| Advised water flux | m³/h | 2 | 2.5-3.2 | 2.5-3.7 | 2.6-5.1 | 3.5-7.1 | 4-7.9 | 4.6-9.3 |
| Water Pressure Drop | KPa | 12 | 12 | 12 | 12 | 15 | 15 | 16 |
| Heat exchanger | Sprial Titanium Tube in PVC shell | |||||||
| Water connection | mm | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| No. of Fan | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| Air side heat exchanging type | Side discharge | |||||||
| Net Weight | kg | 34 | 38 | 48 | 53 | 63 | 75 | 79 |
| Gross Weight | kg | 36 | 40 | 51 | 57 | 67 | 79 | 88 |
| Net Dimension (WxDxH) | mm | 759*300*510 | 759*300*510 | 942*363*550 | 942*363*550 | 1049*413*702 | 1049*413*702 | 1049*413*702 |
