2024 Year Portable Smaller Size Rtk South Galaxy G1 G2 G3 G7 Inno7 G9 Gnss Rtk

Product Description

Product Description
South Galaxy G2 GNSS RECEIVER:
South new generation integrated RTK system with smaller size and innovative design.New generation of embedded Linux operating system platform improves RTK performance and work efficiency, leads the direction of new generation RTK with excellent performance, provides high-efficiency and intelligent surveying experience to customers. It isn't simply smaller, it does better in everywhere.

Detailed Photos

Product Parameters SPECIFICATIONS

Surveying Performance
Channel	965 Channels
Signal Tracking	BDS B1, B2, B3,
	GPS L1C/A, L1C, L2C, L2E, L5
	GLONASS L1C/A, L1P, L2C/A,L2P, L3
	SBAS L1C/A, L5( Just for the satellites supporting L5 )
	Galileo GIOVE-A, GIOVE-B, E1, E5A, E5B
	QZSS,WAAS, MSAS, EGNOS, GAGAN, SBAS
GNSS Feature	Positioning output rate: 1HZ~50HZ
	Initialization time : <10s
	Initialization reliability : >99.99%
Positioning Precision
Code Differential GNSS Positioning	Horizontal: 0.25 m + 1 ppm
	Vertical: 0.50 m + 1 ppm
	SBAS positioning accuracy: typically<5m 3DRMS
Static GNSS Surveying	Horizontal: 2.5 mm + 0.5 ppm
	Vertical: 5 mm + 0.5 ppm
Real-Time Kinematic Surveying (Baseline<30km)	Horizontal: 8 mm + 1 ppm
	Vertical: 15 mm + 1 ppm
	Horizontal: 8 mm + 0.5 ppm
	Vertical: 15 mm + 0.5 ppm
Network RTK	RTK initialization time: 2~8s
Physical
Dimension	12.9cm × 11.2cm
Weigh	970g(includiing installed battery)
Material	Magnesium aluminum alloy shell
Environmental
Operating	-45ºC~+60ºC
Storage	-55ºC~+85ºC
Humidity	Non-condensing
Waterproof/Dustproof	IP67 standard,protected from long time immersion to depth of 1m
	IP67 standard,fully protected against blowing dust
Shock and Vibration	Not operating: Withstand 2 meters pole drop onto the cement ground naturally
	operating : Withstand 40G 10milliseconds sawtooth wave impact test
Electrical
Power consumption	2W
Battery	Rechargeable, removable Litium-ion battery
Battery Life	Single battery: 7h( static mode ) 5h( interual UHF base mode )
	6h( rover mode )
Communications and Data storage
I/O Port	5PIN LEOM external power port + RS232
	7PIN LEOM RS232 + USB
	1 network/radio data link antenna port
	SIM card slot
Wireless Modem	Integrated internal radio receiver and transmitter 0.5W/2W
	External radio transmitter 5W/25W
Working frequency	410-470MHz
Communication protocol	TrimTalk450s, TrimMark3, PCC EOT, SOUTH
Cellular Mobile Network	WCDMA3.5G network communication module, GPRS/EDGE compatible, CDMA2000/EVDO
	3G optional
Double Module blue tooth	BLEblue tooth 4.0 standard, support for android, ios cellphoon connection
	blue tooth + EDR standard
NFC communication	Realizing close range ( shorter than 10cm ) automatic pair between Galxy G1 and controller
	(controller equipped NFC wireless communication module needed)
Data storage/Transmission	4GB internal storage, more than 3 year raw observation data (1.4M/day) base on recording from 14 satelites Plug and play more of USB data transmission
Data Format	Differential data format: CMR+, CMRx, RTCM2.1, RTCM2.3, RTCM3.0, RTCM3.1, RTCM3.2
	GPS output data format: NMEA0813, PJK plan, cordinates binary code
	Network model support: various, FKP, MAC, supporting NTRIP protocol
Intertial Sensing System
Tilt survey	Built-in tilt compensator, correcting coordinates automaticlly according to the tilt direction and angle of the centering rod
Electornic Bubble	Conteroller software display electronic bubble, checking leveling status of the centering rod real time
User Interaction
Buttons	One-button operation, Visual operation, convenient and efficient

Company Profile
Our company to provide professional surveying instruments and surveying service, and with rich experience in export trade, We have many customers abroad. Because of its high cost performance, it is deeply loved by customers all over the world, especially in African countries, Southeast Asian countries, South American countries and Oceanian countries. We have many customers in Tanzania, Uganda, Zambia, Cote d'Ivoire, Cameroon, Zimbabwe, Congo, India, Singapore, Pakistan, Mongolia Brazil, etc. Our company mainly sales of Total station, Auto/digital level, Optical /electronic theodolite, GNSS RTK, Laser distance meter, Handheld GPS, Drone, Surveying accessories, Surveying software, etc. We have good price with Trimble, Hi-target, South, Kolida, Sanding, Ruide, Chc, Stonex, Foif, Tersus, spectra, nikon. etc. And we keep good cooperation with surveying accessory manufacturer. The Company's employees graduated from engineering, surveying professional institutions of higher learning, with professional knowledge, is a high-quality sales and service team to provide you with excellent quality instrument service and efficient surveying solutions. Our goal: Be a best and professional export supplier of surveying instruments.
Packing

Customer feedback
Payment support :

Shipping
FAQ
1. how long we guarantee quality?
Our main products like Auto level, Theodolite, Total Station,Gnss rtk have one year warranty, And we sure the products will be free from maintenance within warranty period If it is not man-made damage,and accessories with 6 month warranty
2.what can you buy from us?
Auto/digital level, Theodolite, Total Station,Gnss rtk,Laser level,Laser distance meter, drone ,3D scanner, Echo sounder and surveying accessories like tripods,ranging pole,prism,bipod .etc
3.what repair service can we provide if products got problem?
For small issues like missing or damaged part, key board, please send us the photos, we will send the required part and related instructions to you for free;
For big issues in one year warranty like EDX board, main board issue. We could only ask you to send the instrument back to us. Normally we will have it fixed in 10 working days and send back to you. You and we shall take care of the corresponding shipping cost on each side. For big issues out of one year warranty, the customer should be responsible for all the cost.
4,what payment term we support?
TT, Paypal, Western union,L/C,Pay in cash
5, How will we prepare before shipment?
All products will have been strictly quality checked in factory before sending out.Usually, we will send out the products within 3-5 working days after the payment confirmed and the buyer are responsible for the tax and/or duty charged by their country.

---
