High Speed Dispersion Mixer Multi-Function Dispersing Machine

US$5,000.00-58,500.00 1 Piece (MOQ)

Basic Info.

Model NO.
ZR-D-01
Application Area
Viscous Material as Sealant, Adhesive, Pastes
Certification
CE
Condition
New
Mixing Drum Shape
Disc
Stirring Type
Spiral
Working
High Speed Mixer
Feature
Dispersing Power Mixing
Character
High Speed
Advantage
No Dead Point
Available
Acrylic, PU, RTV and Htv Sealant
Layout Type
Horizontal
Operating Type
Continuous Operating
Warranty
1 Year
Mixer Type
Cycle Operating
Transport Package
Wooden Case
Trademark
ZR
Origin
China
HS Code
8479820090
Production Capacity
20/Month

Product Description

Silicone Sealant/Glue/Adhesive/Paste Dispersing Equipment Multifunctional Power Mixer Machine Product Description ZR multifunctional dispersing machine is an efficient homogenizing mixer,which is the main equipment for silicone sealant,it can produce high viscosity material according to customer's customized demand requirement. Our dispersion machine has a great sealling and vacuum function as well as its good exhaust defoaming effect. Working capacity range from 100 L to 3000 L.Power is designed according to the material viscosity.
This high speed dispersion mixer has a widely used in adhesive,cosmetics,chemical products,battery,foodstuff,pharmaceutical, plastic industries, and ect.
There is three motors in our dispering mixer to make sure it can provide enough power during working, also there is three stirrers in differnt forms in the Disc, one stirrer rotates around the axis of the Disc body,other two stirres rotates around their axis with different speeds,so all raw material can do complex stirring movement in the Disc by strong shearing and kneading to be base material (PU sealant, RTV sealant, HTV sealant, Acrylic sealant,Paste,ect)
Its "E" type scraper design in our dispering power mixer rotates around the axis of Disc body to scrape out the raw material stuck on the wall and bottom to make the base material have better effect.
Product Parameters
Model: 3000L 1000L 500L 300L 200L 100L
Cylinder Size(MM) Φ1600*1500 Φ1200*1000 Φ1000*850 Φ850*650 Φ750*650 Φ650*450
Design Volume(L) 3014 1130 668 369 265 149
Usable Volume(L) 3000 1000 500 300 200 100
Stirring Power(KW) 30 22 18.5 11 7.5 5.5
Stirring Rotate Speed(r/min) 0-64 0-64 0-50 0-50 0-50 0-50
Dispersing Power(KW) 37*2 30*2 22*2 7.5*2 5.5*2 4*2
Dispersing Rotate Speed(r/min) 0-2500 0-2800 0-2500 0-3600 0-3600 0-3600
Dimension(MM) 3900*2100*4800 2600*1350*2649 2598*1300*3125 2080*1140*2235 1980*1040*1700 1980*940*1600
Weight(KG) 12000 7000 4200 2500 2200 1800
