Large Format Laser Plotter for PCB Industry with High Resolution

US$30,000.00-40,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
BC
Type
External Drum Imagesetters
Automatic Grade
Automatic
Scan Mode
Drum Scanning
Recording Resolution
DPI
Performance Parameters
Repeat Accuracy
Film Size
762*660mm
Scan Resolution
8000-24000dpi
Precision
0.01mm
Operation Mode
Automatic
Size
1120*920*1170
Transport Package
Wooden Cases
Specification
1800
Trademark
DB
Origin
China
HS Code
8442309000
Production Capacity
100sets/Year

Product Description

Technical parameter
Model BC-4600
Film size 660×508mm
Laser channels 650nm LD, 64 channels
Scanning resolution 8000DPI 12000DPI 16000DPI 20000DPI 24000DPI
Min.line space/line width 1.5mil
(0.04mm)		 1mil
(0.025mm)		 0.7mil
(0.018mm)		 0.55mil
(0.014mm)		 0.4mil
(0.01mm)
Scanning time
(Max.film size)
 3min10sec 4min40sec 8min30sec 12min-
50sec		 18min-
40sec
Scanning mode
 External drum
Repeatability
precision
 ±0.01mm
Plate loading
& unloading mode
 Full automatic film loading & unloading, with online film processor
Max.cassette
capacity
 15-20
(with dark room)
Machien size(LxWxH)
 1120mm×910mm×1150mm
Model BC-2630
Film size 762×660mm/762×610mm/660×508mm
Laser channels 650nm LD, 64 channels
Scanning resolution 8000DPI 12000DPI 16000DPI 20000DPI 24000DPI
Min.line space/line width 1.5mil
(0.04mm)		 1mil
(0.025mm)		 0.7mil
(0.018mm)		 0.55mil
(0.014mm)		 0.4mil
(0.01mm)
Scanning time
(Max.film size)
 4min40sec 7min 12min20sec 19min-
25sec		 27min-
40sec
Scanning mode
 External drum
Repeatability
precision
 ±0.01mm
Plate loading
& unloading mode
 Full automatic film loading & unloading, with online film processor
Max.cassette
capacity
 15-20 sheets
(with dark room)
Machien size
(LxWxH)
 1120mm×920mm×1150mm
Weight Around 500KG

Machine picture
