| Model | TP3000W-12V | TP3000W-24V | TP3000W-48V |
| Output power | 3000W |
| Peak power | 6000W |
| Input voltage(Range) | DC12V (9-15.5V ) | DC24V (18-31V ) | DC48V ( 38-61V ) |
| Output voltage(Single) | (100VAC/110VAC/120VAC/220VAC/230VAC/240VAC ) ±5% |
| Unload current less than | <0.9A | <0.4A | <0.2A |
| Output frequency | 50Hz or 60Hz |
| Output waveform | Pure Sine Wave |
| Waveform distortion | THD<3%( Pure resistive Load)) |
| USB | 18W Fast charging |
| Max.output efficiency | 88% | 90% | 92% |
| Low voltage protection | Pre-alarm (alarm off after 1 sound), LED Red light on, voltage contiously reduce and shutdown |
| Over voltage protection | Pre-alarm (alarm off after 2 sounds), LED Red light on, shutdown |
| Over load protection | Continuous alarm, LED Red light on, shutdown |
| Over temperature protection | Pre-alarm (alarm off after 3 sounds), tempurature continously rise, LED Red light on, shutdown |
| V Short circuit protection | Perfect protection and no damage the circuit |
| Input reverse polarity protection | Fuse burn-out |
| Low voltage alarm | 10.5±0.5V | 21±0.5V | 42±1V |
| Low voltage protection | 9.5±0.5V | 19±0.5V | 38±1V |
| Over voltage protection | 15.5±0.5V | 31±0.5V | 61±1V |
| Low voltage recover | 13±0.5V | 24±0.5V | 48±1V |
| Over voltage recover | 14.5V±0.5V | 29V±0.5V | 58V ± IV |
| Working temperature | -20° - +50° |
| Product Dimension(mm) | 435*205*85 |
| Mounting Size(mm) | 405*130 |
| Product Lable Size(mm) | 380*75 |
| Packing(mm) | 500*260*145 |
| Net./gross weight(kgs) | 5.36/6.25 |
| QTY/CTN | 3 PCS |
| Meas./CTN(mm) | 520*460*285 |
| Gross weight/CTN(kgs) | 19.75 |
| Warranty | 24Months |
| DC Cable(mm2) | 35 | 16 | 6 |
| Cooling method | Intelligent air cooling |
| Note: Our products update constantly.The technical parameter is for reference only.Please refer to our real product. |
