Automatic Manual Cutting Bending Machine

US$12,000.00
1-2 Pieces
US$10,000.00
3-4 Pieces
US$9,000.00
5+ Pieces

Basic Info.

Model NO.
HLD-1
Tile Type
Colored Steel
Certification
ISO, ISO9001
Condition
New
Customized
Customized
Usage
Roof, Wall, Floor
Transmission Method
Machinery
Type
Rolling Machine
Forging Forming Method
Tire Mold Forging
Power Source
Hydraulic Pressure
Feature
Automation
Advantage
Use Widely
Size
8m*1.5, *1.5m
Transport Package
3sets/20gp
Specification
6.5*1.3*1.2m
Trademark
HLD
Origin
China
HS Code
8462
Production Capacity
10sets/Month

Product Description

Product Description

(1) Suitable material: Color steel, galvanized steel
(2) Thickness of the plate: 0.3-10.8mm
(3) Input width of the plate: 1250/1000mm
(4)Width of the plate after forming: 1000/800mm
(5) Productivity: 8-10m/min
(6) Roller steps: 16rows
(7) Roller material: 45# steel Rolling chromium thickness: 0.05 mm
(8) Diameter of active shaft: 80mm
(9) Wall thickness of the main forming machine: 16mm steel plate
(10)Main forming machine body: 300mmH steel
(11) Transmission chain is1''
Reducer is 5.5kw which works stably and no noise
(12) Cutting hydraulic systerm adpats CDF-10 gear pump, the motor power is 4kw, no noise, work stably, long life expentancy.
(13) PLC control systerm, easy to operate, high precision and work stably.
(14) Dimensions of major structure: 8500mm*1600mm*1200mm
suitable material color steel, galvanized steel
thickness of the palte 0.13-0.80mm
input width of the plate 1250/1000mm
width of the plate after forming 1000/800
prouctivity 8-10m/min
roller steps 16rows
roll material 45# steel
made board 16mm steel plate
main forming machine body 300H STEEL
transmission chain 1"
