Automatic Indoor Moving Walks with Vvvf Control Device

Product Description

Automatic Indoor Moving Walks with Vvvf Control Device
Configuration of high standard energy saving scheme
Moving walk standard energy-saving inverter,direct drive host, in no one or no load, low-speed operation, realize the energy saving and the highest energy saving up to 30%.
Moving walk standard aluminum pedal
Reduce the overall weight of the moving parts, the same can reduce power consumption. Using the six stage motor with high quality reduction box, the operation efficiency is high, and the mute effect is realized.
***************************************************
For detail information, please contact us.
***************************************************

Lifting height H(mm)	Speed V	Stair width A (mm)	Angle of Inclination	Power of driving motor(kw)	Center distance of handrail B (mm)	Width of handrail shape C(mm)	Width of pit D(mm)
10000≤L≤80000	0.5	800	0-6	8	1038	1400	1460
80000<L≤110000				11
10000≤L≤80000	0.5	1000	0-6	8	1238	1600	1660
80000<L≤110000				11

0°-6° MOVING WALK CONSTRUCTION SKETCH
Features
1. Safe and reliable
Our passenger elevator puts safety the first place, to ensure each passenger's safe delivery to destination.
2. Space configurability
From the view of space saving, Our passenger elevator make new layout of machiine room, improved the space availability.
3. Energy saving and environment friendly
Our passenger elevator adopts gearless permanent magnet synchronous machine to save energy and protect environment.
4. High performance
Our passenger elevator is euipped with stable control system. Intelligent lift dispatching system provides the best solution for customer riding.
5. Free custom-made
Customers can choose their favorite and customized apperance for their own elevators.
Our factory
Delivery
About us
Why choose us? Shanghai Sunny Elevator Co., Ltd, founded in 1992, is a 30-year professional manufacturer specializing in designing and producting Opto-Electro-Mechanical products.
Sunny Elevator has started import and export since 2012.
We have experience for exporting all kinds of elevator & elevator parts to 80 countries all over the world.

---
