Product Details
Product Description
Product Description
1. Product Guide
PFA transparent tubes are used to transport different liquids and gases, and are resistant to strong acids and alkalis, high and low temperatures. Different British tubes and capillaries can be processed. They are used in industries with high cleanliness requirements such as the petroleum industry, biopharmaceuticals, and the semiconductor industry. PFA tubes are used for liquid and gas transportation during semiconductor manufacturing. In semiconductor processes, many liquid and gas media need to be transported under high temperature conditions while maintaining high purity and chemical inertness. PFA tubes are ideal for transporting chemicals and solvents due to their excellent high temperature resistance and inertness to chemical corrosives, such as acid and alkali solutions, sputtering source materials, photoresists, and deionized water.
2. Technical parameter description
Product name: PFA delivery pipe
Outer diameter * inner diameter (mm): 6*3, 6*4, 7*5, 12*10, British 1/4 inch 6.35*4.35, British 1/8 inch 3.17*1.58 Material: PFA
Temperature tolerance -200-260℃
3. Product characteristics:
1. High and low temperature resistance: The operating temperature can reach -200~+260℃, and it can work at freezing temperature for a long time without becoming brittle, and it will not melt at high temperature
2. High chemical stability can withstand All strong acids, including aqua regia, hydrofluoric acid, concentrated hydrochloric acid, nitric acid, fuming sulfuric acid, organic acids, etc., strong alkalis, strong oxidants, reducing agents and various organic solvents, are used for the transportation of various harsh fluids.
3. Low dissolution and precipitation, it is a good vessel for storing standard substances, highly corrosive, expensive high-purity reagents.
4. Outstanding non-stickiness, excellent anti-stickiness, no colloids and chemicals adhere to the inner wall of the tube, so no dirt layer will be formed in the tube.
5. It can be used as a high-purity reagent delivery tube, such as for chromatographs, chemical equipment, etc. supporting pipelines. Semiconductor, liquid crystal manufacturing equipment, chemical plants and other liquid pipelines.
6. Very good aging resistance and radiation resistance can be used outdoors for a long time.
7. High softness and bending resistance.
Our factory can process in a directional manner.
