| Processor | Intel Gemini Lake/Gemini Lake-R |
| Graphics | Intel UHD Graphics 600 |
| Display | 1*VGA Port |
| 1*HDMI1.4, Max Reslution 4096X2160@30Hz | |
| Memory | 1*DDR4 SO-DIMM，Max.8GB DDR4/2400MT/s |
| Ethernet | 6*LAN, intel i211， Supports WOL、PXE Boot |
| Storage | 1*SATA3.0 |
| 1*mPCIE，Supports mSATA SSD | |
| Expansion | 1*mPCIE，Supports 4G/3G Module |
| 1*SIM Card reader | |
| Rear Panel I/O | 1*DC_IN |
| 1*HDMI | |
| 1*VGA | |
| Front I/O | 1*PWR_BTN |
| 1*RST_BTN | |
| 2*USB3.0 | |
| 6*RJ45 | |
| 1*COM | |
| 1*PWR_LED | |
| 1*HDD_LED | |
| Internal I/O | 1*CPU_FAN |
| 1*SYS_FAN | |
| 1*SATA3.0 | |
| 1*SATA_PWR | |
| 1*ATX_4P | |
| 1*SIM | |
| 1*VGA_H | |
| 2*mPCIE | |
| 1*AUTO_ON | |
| 1*CLR_CMOS | |
| 1*LAN_LED | |
| 1*F_Panel | |
| 1*F_USB header | |
| BIOS | 64M Flash ROM |
| Power Supply | DC 12V |
| OS | windows10/11/Linux |
| Heat Sink | Smart Fan |
| OTR | -10℃～60℃ |
| STR | -20℃～70℃ |
| Humidity | 5%-95% Relative Humidity,Non-condensing |
| Dimension | 180*200mm |
