| Product name | DMH 2,81-200D B-SS/V/C-R-E2B6B6XEMAG |
| Product No | 99823891 |
| EAN number | 5713834809804 |
| Nominal flow rate at 50 Hz | 2.81 l/h |
| Number of dosing heads | 2 |
| Approvals | CE,EAC,CNROHSEX |
| Non return valve type, inlet pump 1 | Ball valve, spring-loaded |
| Non return valve type, outlet pump 1 | Ball valve, spring-loaded |
| Max viscosity | 5 mPas |
| Pump housing | Aluminium |
| Dosing head, pump 1 | Stainless steel |
| EN 1.4571 | |
| Dosing head, pump 2 | Stainless steel |
| EN 1.4571 | |
| Valve ball | Ceramic |
| Al2O3 | |
| Valve seat | Composite |
| PTFE | |
| Valve gasket | FKM |
| Rubber |
| Max operating pressure at 50 Hz | 200 bar |
| Maximum permissible inlet pressure | 1 bar |
| Type of inlet connection | Cutting ring |
| Type of outlet connection | Cutting ring |
| Size of inlet connection | 4/6 |
| Size of outlet connection | 4/6 |
| Pumped liquid | Water |
| Liquid temperature range | -10 .. 90 °C |
| Selected liquid temperature | 20 °C |
| Density | 998.2 kg/m³ |
| Power input P1 | 0.2 kW |
| Mains frequency | 50 Hz |
| Max. frequency | 50 Hz |
| Rated voltage | 3 x 230/400 V |
| Enclosure class (IEC 34-5) | IP65 |
| Cable included (Yes/No) | N |
| Power plug | No plug |
| Type of connector | No plug |
| Type of control variant | Standard |
| Frequency converter | Not prepared for VFD |
| Net weight | 23 kg |
| Gross weight | 34.3 kg |
| Shipping volume | 0.156 m³ |
| Diaphragm Leakage Detection | N |
