Power Transmission Line Machine Angle Master Tower Manufacture Punching Shearing Notching Marking CNC Machine

Product Description

Product Description
The machine with opening C-type structure, its cutting mould is rectangular double-blade mode. Multi-directions rotational corner cutting mould can cut out different angle of angles only need to adjust rotation die-carrier so as not to rotate the angles, so corner cutting with little error only need small working area.

Product Parameters

Model	RHC140	RHC160	RHC200
Functions	Used for cutting corner of angles in steel tower industry
Nominal pressure(kN)	800	1000	1600
Stroke of oil cylinder(mm)	50	50	50
Times of stroke(min-1)	20~25	20~25	20~25
Power of motor(kW)	15	15	22
Angle steel size(mm)	L40×40×3~ L140×140×12	L40×40×3~ L160×160×16	L40×40×3~ L200×200×20
Rotary angles	360° manual
Dimensions of notching mould(mm)	650×650×500	700×700×500	830×700×600
Dimensions L×W×H(mm)	1270×1020×1800	1300×1020×1880	1370×1120×1900

Company Profile
AI-Machine(Shandong) Industry Technology Co.,Ltd is a high-tech company known for its advanced technology and perfect after-sales service. The company is mainly engaged in CNC Machines for angle steel tower, CNC Machines for steel structure ,CNC metal coil processing complete sets of equipment, like circle blanking line, cross-shear line, slitting line for hot-rolled and cold-rolled series plate. Design and manufacture of other non-standard equipment; design and manufacture of hydraulic and electric control systems; design and manufacture of special hydraulic machinery.
We have been engaged in design and development for many years and have a technical team with rich manufacturing experience, and have advanced production equipment as the backing.
We have a complete after-sales service network, which can provide you with full support from pre-sales to after-sales, so that you can get the most satisfactory equipment, to ensure that you solve all the problems you encounter in the most convenient and timely manner during use, and get our thoughtful services. Create your future with our technology and services.
Other products
FAQ
1. The delivery time?
For machines available in stock, the shipment can be arranged within 15 days after getting advance payment or L/C;
For machines non available in stock, the shipment can be arranged with 60 days after getting advance payment or L/C.
2. After-sale service?
1) We can send you free components if machines are in warranty period;
2) 24 hours service on line;
3) We can assign our engineers to serve you if you want.
3. Installation and Training?
Yes. We can send professional engineers to the working site for machine's installation, commissioning and operation training.
4. Model choose?
Please share us your material size and your processing request, then we will recommend our machine most suitable and most cost effective for your work demand.

---
