NetEngine 5000E core routers
NE5000E-X16B CR5BBKP6BA60: Assembling Components,CR5Z5BKP16G01,NE5000E-X16B Integrated Chassis Components (AC Power)
Hua wei NetEngine 5000E core routers are designed to be used as an enterprise backbone network node, metro network core node, Data Center Interconnect (DCI) node, or international gateway. Offering high capacity, high reliability, intelligence, and energy-saving capabilities, NetEngine 5000E support single chassis, back-to-back chassis, and multi-chassis cluster modes: this allows on-demand expansion, enabling enterprises to handle rapid Internet traffic growth and future service development with ease.
Technical specification
1.Hardware Specifications Item Specification

Cabinet installation standards	Can be installed in a 1000 mm-deep standard 19-inch cabinet and is installed in a 2200 mm-high Hua wei N610E cabinet by default.
Dimensions without packaging (H x W x D) [mm(in.)]	1778 mm x 442 mm x 650 mm (70 in. x 17.4 in. x 25.59 in.)
Chassis height [U]	40 U
Weight without packaging [kg(lb)]	148 kg (326.28 lb)
Weight without packaging (full configuration) [kg(lb)]	1T single-chassis (full configuration): 376 kg (828.94 lb) 2T cluster (full configuration): 434 kg (956.81 lb)
Typical power consumption (with configuration) [W]	1T single-chassis:12300 W 2T single-chassis:19100 W
Typical heat dissipation (with configuration) [BTU/hour]	1T single-chassis:39906.4 BTU/hour 2T single-chassis:61968.4 BTU/hour
MTBF [year]	12.20 year
MTTR [hour]	0.5 hour
Availability	0.99999
Power supply mode	AC/HVDC built-in
Maximum number of power chassis inputs	(4 channels/PEM) x 4 PEM=(1 channel/PM) x 4 PM x 4 PEM=16 channels
Rated input voltage [V]	AC: 200 V to 240 V HVDC: 240 V/380 V
Input voltage range [V]	AC: Voltage range:180 V to 264 V 220 V rated voltage:200 V to 240 V HVDC: 192 V to 400 V
Maximum input current [A]	AC:16A/single-module HVDC:14A/single-module
Maximum input cable size [mm²]	AC: Standard C19 cable HVDC: 2.5 mm²
Front-end circuit breaker/fuse [A]	AC:16 A/single-module HVDC: 14 A/single-module [1T bundle]HVDC device: 14 PMs, in need of 14 channels of 14A [2T bundle]HVDC device: 16 PMs, in need of 16 channels of 14A
Noise at normal temperature (acoustic power) [dB(A)]	Complies with the NEBS standard (< 78 dB(A) @ 27°C).
Number of slots	22
Number of service board slots	16
Switching capacity	81.92 Tbit/s
Redundant MPUs	1:1
Redundant Switch fabrics	3+1
Redundant power supply	N+N
Redundant fans	Consists of upper and lower areas. Three fan modules. If a single fan fails, the system can still work for a short period of time at an ambient temperature of 40°C.
Long-term operating temperature [°C(°F)]	0°C to 40°C(32°F to 104°F)
Short-term operating temperature [°C(°F)]	-5°C to 50°C (23°F to 122°F)
Restriction on the operating temperature variation rate [°C(°F)]	≤ 0.5°C/min (32.9°F/min), non-condensing
Storage temperature [°C(°F)]	-40°C to +70°C (-40°F to +158 °F)
Long-term operating relative humidity [RH]	5% RH to 85% RH, non-condensing
Short-term operating relative humidity [RH]	5% RH to 95% RH, non-condensing
Storage relative humidity [RH]	5% RH to 95% RH, non-condensing
Long-term operating altitude [m(ft.)]	3000M @ 40°C
Storage altitude [m(ft.)]	< 5000 m (16404.20 ft.)

2.Ordering Information Description Part Number Model

Assembling Components,NetEngine5000E,CR5BBKP6BD01,NE5000E-X16B 220V AC/240V DC Integrated Chassis Components	02350CME	CR5BBKP6BD61
Assembling Components,NetEngine5000E,CR5BBKP6BD02,NE5000E-X16B 380V DC Integrated Chassis Components	02350CMF	CR5BBKP6BD62
Assembling Components,CR5Z5BKP16G00,NE5000E-X16B Integrated Chassis Components (DC Power)	02359085	CR5BBKP6BD60
Assembling Components,CR5Z5BKP16G01,NE5000E-X16B Integrated Chassis Components (AC Power)	02359086	CR5BBKP6BA60
