Specification
| Model B5020
| Model B5032
|
Ram stroke
| 220mm
| 340mm
|
Max length of the ram slotting
| 200mm
| 320mm
|
Ram movement times
| 32.50.80.125 time min
| 20.32.50.80 time min
|
Tiltram
| 0-8°
| 0-8°
|
Table dia.
| 500mm
| 630mm
|
Vertical adjustment of ram distance
| 230mm
| 315mm
|
Head bearing surface to the bed from the front walls
| 485mm
| 600mm
|
Between the work surface to the lower carriage distance
| 320mm
| 490mm
|
Table max.longitudinal movement distance
| 500mm
| 630mm
|
Table max. lateral movement distance
| 500mm
| 560mm
|
Max. swivel table
| 360°
| 360mm
|
Table aspect motorized feed range
| 0.08-1.21
| 0.08-1.21
|
Table rotation feed range
| 0.052-0.783
| 0.052-0.783
|
Main motor
| 3kw
| 4kw
|
Motor speed (calulated value)
| 1430 r/min.
| 960 r/min.
|
Machine weight
| 2200 kg
| 3000 kg
|
Overal dimension
| 1916×1305×1995mm
| 2261×1495×2245mm
|
