Efficient Tube Mill Line, Proven and Durable, Ensuring Optimal Tube Producing in Your Processes

US$1,000.00-1,500.00 1 Ton (MOQ)

Basic Info.

Model NO.
7-273mm
Condition
Used
Customized
Non-Customized
Theory
Pulse
Application
Industry, Decoration
Type
Pipe Welding Machine
Rust-Removal
Provided
Maintenance
Provided
Repainting
Provided
Full Set
Yes
Auxiliary Equipment
Included
Transport Package
Provided
Specification
Tube Mill
Trademark
None
Origin
China
Production Capacity
3000 Sets / Year

Product Description

High Frequency Welding Tube Mill Line:
Main Process
Uncoiler→ beading & pressure-guiding/straight head leveling/leveler→ shear-butt welding→ horizontal spiral loop→ forming unit→ solid high frequency power supply→ outer-burr removal device→ bead polishing device→ cooling channel→ sizing mill group→ straightening→ computer flying saw→ pneumatic turning rack
Product specification:
Type Welded pipe Dia (mm) Pipe wall thickness (mm) Welding speed (m/min) Main motor power(KW) Solid high frequency power supply (kW)
VZH-16 φ7-18mm 0.3-1.0mm 30-120m/min 22kW 60kW
VZH-20 φ9-26mm 0.3-1.2mm 30-120m/min 37kW 60kW
VZH-25 φ10-30mm 0.4-1.5mm 30-100m/min 45kW 100kW
VZH-32 φ12.7-38.1mm 0.5-1.75mm 30-100m/min 75kW 100kW
VZH-32z φ12.7-38.1mm 0.6-2.0mm 20-90m/min 45kW*2 100kW
VZH-45 φ16-50.8mm 0.6-1.5mm 20-80m/min 45kW*2(90kW) 150kW
VZH-45z φ16-50.8mm 0.7-2.5mm 20-75m/min 55kW*2(132kw) 150kW
VZH-50 φ20-63.5mm 0.7-3.0mm 20-75m/min 75kW*2 200kW
VZH-60 φ25-76mm 0.8-3.25mm 20-70m/min 90kW*2 250kW
VZH-76 φ30-101mm 1.0-3.75mm 20-70m/min 110kW"2 300kW
VZH-89 φ35-114mm 1.2-4.25mm 20-70m/min 132kW*2 300kW
VZH-114 φ40- 127mm 1.5 - 5.0 mm 15-60m/min 160kW*2 400kW
VZH-125 φ50-130mm 1.8-5.5mm 10-50m/min 185kW*2 400kW
VZH-165 φ60-165mm 2.0-6.0mm 10-50m/min 200kW*2 400kW
VZH-165z φ76-168mm 2.5-8.0mm 10-50m/min 200kW+110kW*2 500kW
VZH-219Q φ76-219mm 2.0-6.0mm 10-40m/min 90kW*2+110kW*2 500kW
VZH-219 φ89-219mm 3.0-8.0mm 10-40m/min 110kW*2+132kW*2 600kW
VZH-219z φ89-219mm 4.0-10.0mm 10-40m/min 132kW*2+160kw*2 700kw
VZH-273 φ100-273mm 4.0-10.0mm 10-40m/min 160kW*2+185kW*2 700kW
VZH-273z φ114-273mm 4.5-12.0mm 10-30m/min 185kW*2+200kW*2 800kW
