| Model | JBZ-236 | JBZ-217 |
| Needle type | Latch needle | Latch needle |
| Machine type | E2 E3 | |
| Working width of the machine | Max 6 Meter | 5.4 Meter |
| Quantity of carding combs | 4/5piece | |
| Control Speed | Inverter | |
| Automatic Stop Service | Weft Broken ,automatic Stop | |
| Warp feeding style | Positve warp feeding by three rollers | |
| Adjustment range of traction density | 1.31-14.5coils/cm | |
| Max. winder diameter | 1200mm | |
| Capacity | 40Meter/Hour | |
| Revolution of main shaft | Max 600RPM | |
| Drive motors | Main motor: 5.5kw Winding motor: 0.8kw | |
| Total weight | 12000kg | |
| Overall dimensions(L*W*L) | 7200/8200*7000*2400MM | |
