Milk Powder Making Stainless Steel Spray Drying Machine/brewery Yeast Spray Drying Machine

Product Description

Product Description
Product Description
Product View
Milk Powder Making Stainless Steel Spray Drying Machine/brewery Yeast Spray Drying Machine
Working principle
The spray has just entered into an open circulation, parallel flow, centrifugal atomization. The air of the drying medium is filtered by the primary and intermediate efficiency air filters and then sucked by the blower according to the operation instructions and heated by the heater through the hot air distributor of the high-efficiency filter to enter the main tower of the spray drying. The liquid material passes through the peristaltic pump according to the operation instructions, enters the centrifugal nozzle rotating at high speed, and is dispersed into small droplets under the action of centrifugal force. In the main tower of spray drying, the small mist droplets are in full contact with the hot air, heat exchange along its specific path, and then dried to become a product, and then separated by a cyclone separator, the solid materials are collected, and the gas medium is filtered and discharged . The entire spray system is easy to clean and has no dead corners, and meets GMP standards.
The high-speed centrifugal spray dryer is a special drying equipment suitable for drying liquids such as emulsions, suspensions, pastes and solutions. Centrifugal spray dryers, spray dryers, and spray drying towers are widely used processes in the liquid forming process and the drying industry.
Uses
Suitable for the production of powdered and granular solid products from suspended emulsions, solutions, emulsions and pasty liquid raw materials. Therefore, when the particle size distribution, residual moisture content, bulk density and particle shape of the finished product all meet precise standards, the spray dryer is an ideal drying process. In polymers and resins; dyes, pigments, ceramics, glass; rust removers, insecticides; carbohydrates, dairy products; detergents and surface activities; wastes; mailing compounds, inorganic compounds liquid Of drying.
Centrifugal Liquid And Egg Powder Making Spray Drying Machine
Coffee Egg Milk Powder Making / Coconut Milk Spray Dryer
Egg Powder Making Machine
Spray Dryer Machine/Spray Drying Machine for Fruit Powder
Structure and characteristics:1. The spray drying speed is fast, and the surface area of the material liquid is greatly increased after being atomized. During the contact with the hot air, 95% -98% of the water can be evaporated in an instant. The drying time is only a few seconds, especially suitable for heat-sensitive materials. dry.2. The product has good uniformity, fluidity and solubility, the higher the purity of the product, the better the quality.
3. The production process of the spray dryer is simplified, and the operation and control are convenient. For the liquid with a moisture content of 40-60% (up to 90% for special materials), it can be dried into a powder product at a time. After drying, it does not need to be crushed and screened, reducing the production process and improving the purity of the product. The product particle size, bulk density, and moisture can be adjusted within a certain range by changing the operating conditions, which is convenient for control and management

Model	OR-LGP5	OR-LGP25	OR-LGP50	OR-LGP100	OR-LGP150	OR-LGP200
Inlet temperature	140°C-350°C Adjustable	140°C-350°C Adjustable	140°C-350°C Adjustable	140°C-350°C Adjustable	140°C-350°C Adjustable	140°C-350°C Adjustable
Outlet temperautre	80°C -90°C	80°C -90°C	80°C -90°C	80°C -90°C	80°C -90°C	80°C -90°C
Maximum water evaporation	5kg/h	25kg/h	50kg/h	100kg/h	150kg/h	200kg/h
Maximum speed (r.m.p)	25000	22000	21500	18000	18000	16000
Heating rouse	Electric	Steam+Electric	Steam+Electric/gasoline/coal gas/hot-blast stove
Heating power	8KW	31.5KW	60KW	81KW	99KW	---
Dimension	1.61.11.75m	42.74.5m	4.52.85.5m	5.547m	75.57.2m	7.568m
Lifting height of nozzle	-----	2.5m	2.5m	3.2m	3.2m	3.2m
Dry powder recovery rate	≥95%	≥95%	≥95%	≥95%	≥95%	≥95%

Product Display
Packing & Delivery
Packing: The normal package is wooden. If export to european countries,the wooden box will be fumigated.
FOB
Sea freight
Air freight
About us
Company ProfileLuohe Orange Mechanical Equipment Co.,Ltd (Orange) is a professional mechanical equipment manufacturer which is located in Henan Province, China. The company is specialized in production, processing and sales of food machinery, agriculture machinery and other machineries. The main production scopes that we cover are: snack food processing machines, candy processing machines, fruit and vegetables processing machines, packaging machines, water well drilling machines, and various peeling machines.
The company covers 35,000 m2and the fixed asset of the company is RMB 10 million Yuan. There are over 100 employees, more than 30 technicians, and over 100 sets of various manufacturing equipment. The equipment are included: large scale forcing press machine, digital lathe, digital wire-electrode cutting equipment, various kinds of processing machines and equipment, etc. The company owns national patents and proprietary technology with independent ....
Our Service
1. Inquiry and consulting support
2.Sending machine video for reference
3.Testing machine before delivery according to requirements.
4.View our Factory
After-sales service
Help training customer operation machine
Solve the customer's problem when machines in use through online video
The large equipment or complex machine , appointed engineer overseas service
