Heavy Duty Big Gap Bed Metal Lathe Machine Cw62103c

Product Description

FEATURE===Heavy Duty Big Gap Bed Metal Lathe Machine CW62103C
SPECIFICATION===Heavy Duty Big Gap Bed Metal Lathe Machine CW62103C

Model	Unit	Model
		CW62103C	CW62123C	CW62143C	CW62163C	CW62183C
Swing over bed	mm	1030	1230	1430	1630	1830
Swing in gap	mm	1200	1400	1600	1800	2000
Swing over cross slide	mm	700	900	1100	1240	1440
Distance between centres	mm	1500; 2000; 3000; 4500;6000
Length in gap from face plate	mm	380
Spindle nose		C11 or D11
Spindle bore	mm	105,130
Spindle speeds	rpm/steps	10-800/18 7-576/18 6-480/18
Cross slide travel	mm	615 715 815 915
Top rest travel	mm	225 300
Rapid traverse	mm/min	Axe Z:3200 ,Axe X:1400
Quill dismater	mm	120
Quill travel	mm	270
Quill taper		MT6
Bed width	mm	610
Metric threads	mm/kinds	1-240/53
Inch threads	tpi/kinds	30-2/31
Module threads	mm/kinds	0.25-60/42
Diametral pitch threads	tpi/kinds	60-0.5/47
Longitudinal feeds	mm/r	0.07-16.72
Cross feeds	kw	0.04-9.6
Main motor power	kw	11
Packing size (mm)	Length	3840; 4340; 5170; 6670; 8290
	Width	1700	1700	1850	2000	2200
	Height	1980	2080	2220	2280	2380
Gross weight	Kgs	5900	6500	7200	7800	8600
		6250	6850	7400	8200	9000
		6900	7500	8100	8900	9700
		8000	8600	9000	9800	10600
		9000	9600	10000	10500	11200

DETAILS=====Heavy Duty Big Gap Bed Metal Lathe Machine CW62103C
ACCSSORIES====Heavy Duty Big Gap Bed Metal Lathe Machine CW62103C
PACKAGE:
CERTIFICATE:
EXHIBITION:
Our Services:
1. Your inquiry and email will be replied within 24hours.
2. If you need to develop products with your own specification, we can help you to work it out.
3. Always be honest, never lie to customer, and never declare anything we don't have.
4. Customer First:,we offer best Quality and Service!
FAQ:
1. Payment Method:
30% deposit T/T in advance, rest against the copy of B/L or before delivery.
2. Delivery Time:
one week
3. MOQ:
1 set machine.
If you need machine with your own specification, logo, packing, etc, please negotiate with us.
4. Shipping:
For machine: Usually by sea;
For documents: by international express, eg. DHL,TNT or EMS
CONTACT:
