| AUTO TYPE TEMPERATURE GAUGE SPECIFICATIONS | |||
| Dial Diameter: | 52mm, 63mm | ||
| Case: | Steel, zinc plated | ||
| Accuracy: | ±2.5% | ||
| Frame: | Steel, black oven painted | ||
| Panel Connectiion: | U clamp | ||
| Working system | Liquid-based spiral bourdon tube CuSn 8or Stainless Steel | ||
| Lighting | 12 V or24 V | ||
| Capillary Tube | 2mm ( can be changed on the request) | ||
| Application | Trucks, Tractors, boat and so on. | ||
