X6232Cx16 Universal Rotary-Head Knee-Type High Speed Milling Machine

Product Description

X6232Cx16 Universal Rotary-Head Knee-Type High Speed Milling Machine
(Picture for reference only)
The Universal Rotary-head Knee-type milling machine is widely used in the machining workshop, with optional accessories as dividing head, rotary table, machine vice, transmission box, boring and facing milling head, milling chuck, etc. Its machining scope/capacity greatly enlarged. X6232B/1: Digital readout(2 dimensional or 3 dimensional) is added to X6232B machine which can improve the machining accuracy and producing efficiency. X6232X16 The same as X6232B, except that the Table length Extended to 1600mm
Specifications:

Product Name:	Universal Rotary Head Milling Machine
Product Type:	X6232B	X6232Cx16
Work table area (width*length):	320* 1320mm	320* 1600mm
T-slots(number of slot-width*pitch):	3-18* 70mm	3-18* 70mm
Work table Max. weight of workpiece:	500Kg	500Kg
Work table swivel angle:	±45°	±45°
Max.stroke longitudinal/transversal/vertical (manual) vertical(power-driven):	680/240/ 300mm	780/240/ 300mm
Max.stroke longitudinal/transversal/vertical(power) vertical(manual):	700/255/ 320mm	800/255/ 320mm
Distance from vertical spindle nose to table surface:	40 -425mm	50 -570mm
Distance from center line of horizontal spindle to table surface:	30 -350mm	30 -350mm
Vertical milling head max. swivel:	360°	360°
Spindle motor power (horizontal/vertical spindle):	5.5/3Kw	5.5/3Kw
Spindle taper(horizontal/vertical spindle):	XT50/XT40	XT50/XT40
Spindle speed range - horizontal vertical spindle	18 steps 30-1500 9 steps 90-1400r/min	18 steps 30-1500 9 steps 125-2000r/min

WHY CHOOSE HAVEN BRAND MACHINE:
1) Hihg quality with competitive price
2) 15 years export experience
3) CE,SGS, ISO Certificated
4) OEM SERVICE AVAILABLE
5) 24 HOURS' ONLINE SERVICE (MSN,SKYPE)
6) 14 months quality warranty (after B/L date)
7) Over sea engineers available for problem shooting

Our Target: BRAND HAVEN
High quality;
Assured Delivery;
Vigorous innovation;
Efficient Cooperation;
Noblesse Oblige

---
