High Quality Diesel Engine High Pressure Hydro Blasting Pump 20000psi

Product Description

MEGAJET SUPER HIGH PRESSURE DIESEL WATER BLASTING MACHINE
Introductions:
Worldwide, thousands of contractors, plants, municipalities, and the military turn to Megajet for our comprehensive offering of industrial, high-pressure waterblast equipment, parts and accessories. These demanding customers keep coming back to Megajet year after year for the superior performance of our products and the unmatched technical support and customer service available to them day and night.
Megajet diesel units, designed for maximum reliability and simplicity, are available in a wide selection of standard models with nearly limitless options for customization to suit specific needs.
Standard Features:
• High performance diesel engines from 110 to 500
horsepower (82 to 373 kW):
° John Deere ° Volvo
° Cummins ° Deutz
° Caterpillar
• Jetstream UNx ® pump.
° Superior performance, greater flexibility in the field,
and reduced downtime and maintenance.
° Field convertible to handle any job.
° See UNx Features and Benefits on page B-1
• PTO and covered belt drive
• State-of-the-art controls
° Easy-to-use control panel with high-visibility gauges.
° Hand-adjustable bypass valve (see page C-13)
• Dual rupture disc holders (see page G-1)
• Heavy-duty galvanized frame
• Atmospheric water tank.
• Water filtration system with stainless steel filter(s)
• Comprehensive safety warning decal package
• Sealed weatherproof electrical wiring
Specifications:

Engine Power		Approximate Unit Weight			UNx Pump	Plunger Stroke		Plunger Size	Max. Pump Displacement		Max. Operating Pressure
HP	KW	Type	lbs	kg		in	mm		gpm	lpm	psi	bar
80	60	Trailer	4850	2200	3020	3.00	76	6	6.2	23.5	20000	1379
		Skid	3850	1750
110	82	Trailer	4850	2200	3020	3.00	76	6	7.4	28.0
		Skid	3850	1750
125	93	Trailer	5100	2320	3020	3.00	76	7	9.0	34.1
		Skid	4100	1860
152	113	Trailer	6700	3040	3620	3.63	92	8	11.8	44.6
		Skid	5600	2540
174	130	Trailer	6500	2950	3620	3.63	92	8	13.0	49.3
		Skid	6050	2750
215	160	Trailer	7950	3610	4220	4.25	108	8	13.9	52.5
		Skid	7300	3310
260	194	Trailer	8050	3650	4220	4.25	108	9	17.6	66.5
		Skid	7400	3360
325	242	Trailer	9450	4290	4220	4.25	108	10	21.4	81.0
		Skid	8550	3880
500	373	Skid	15000	6800	5020	5.00	127	11	39.5	150

Standard Models
• Four-wheel tandem trailer (above)
• Gooseneck trailer
• Standard skid
• Offshore skid (tested and certified to DNV standards)
• C-Series compact units (see the following page for more
information)
Versatility
• Fast, in-the-field pressure range conversion with simple
bolt-on Jetstream UNx Fluid Ends
• Convertibility of the UNx design allows one unit to do the work that another manufacturer would require multiple units or several hours of downtime to perform
Typical Applications
Megajet diesel units are the ultimate solution for a variety of applications, including:
• Surface preparation • Stripe removal
• Coating removal • Tank cleaning
• Tube cleaning
Options
• Fuel-saving hydraulic throttle control idles engine when system pressure is relieved
• Charge pump for pressurized feed
• Greaseless spread-bearing PTO
• Manual transmission drive
• Packing lube water recirculation package
• Safety package with fire extinguisher and grounding strap
• Severe service relief valve to replace one rupture disc holder
• Shut-in regulator valve
• Safety watch shutdown system
• Air-compressor package
• Direct water feed (no water tank)
• Hose reel
• Toolbox to store additional fluid ends, supplies, and tools
• Workbench and vise
• Racks for hoses, guns and lances
• Low water shutdown system
• Lifting bail
• Pump oil level and temperature shutdowns
Trailer Options
• Hydraulic or electric brakes
• LED lighting
• ICC trailer lighting
• Ball or ring coupler
• Aluminum wheels
• High-visibility striping around frame
Count on Megajet for the products and value-added services that make the difference!
• Waterblast equipment up to 40,000 psi (2750 bar)
• Thousands of high-quality parts and accessories in stock and available for same day shipping
• 24/7 Support Program
• Comprehensive web site with online parts ordering
• High-caliber domestic and international sales teams offer unmatched expertise in products and applications to provide the best solution for any job
• Start-up training on all new equipment
• Fully staffed engineering and R&D departments
• Innovative UNx ® Fluid End - up to 40,000 psi (2750 bar) with upgrades available for most popular pumps, including NLB, Butterworth and Woma

FAQ

Q: What's your advantage? A: Advanced production technology, full testing equipments, lower price, shorter delivery time,
high quality after sale guarantee. Q: What is the delivery time? A: Usually 7-30 days. Q: Are factory or trading company? A: We are a leading manufacturer in water blasting and jetting industry.Welcome to our factory any time! Q: What is your main products? A: High Pressure Water Jetting Equipment and accessories is our main products. Q: How to place the order A: You can inquiry and email us.

---
