Automatic Paper Cover Machine Paper Lid Forming Machine

Product Description

Automatic paper cover machine paper lid forming machine

TYPE	DPJ-100	DPJ-145	DPJ-200
NAME	CUP LID MACHINE	BOWL LID MACHINE	BIG BOWL LID MACHINE
LID SIZE	40-100	100-145	145-200
MAX SPEED	70-100PCS/MIN	70-100PCS/MIN	60 PCS/MIN

Technical Parameters
Customs code: 8441309000
Paper cover specifications:
height (8-15) mm, DPJ-100/S100 diameter (60 -100) mm, speed: (70-100) pieces per minute.
Height (8-15) mm, DPJ-145/S145 straight strength (100-140) speed: (60-75) per minute.
Height (8-15) mm, DPJ-200/S200 diameter (140 -200) mm, speed: (45-60) pieces/min
Applicable paper: single and double PE/PLA coated paper, coated paper, glazing coated paper (250-480g/m2)
Power: 10kw
Power supply: AC380V 3-phase, 50Hz (can be customized according to customers)
Working air source: air consumption 0.02 cubic meters per minute, working air pressure 0.3MPa
The total weight of the equipment: Cup lid machine .2100KG.
Bowl cover machine.2500KG.
bowl machine 3300KG.
Cup lid machine packaging size 1920*1640*2000
Bowl cover machine packaging size 2200*1880*2100
bowl lid machine packaging size 2600*1850*2200

---
