Basic Info.
Function
Green Signal, Red Signal, Yellow Signal, Flash Alarm Signals, Direction Signals, Traffic Signal Wand, Lane Signals, Crosswalk Signal, Command Signal
Control Method
Timing Control
Housing Material
Metal Shell
Mask Specification
Φ200mm
Surface Treatment
Hot-DIP Galvanized
Raw Material
Q235B/A36/Q345b/A572, Q460, ASTM573 Gr65, Gr50
Welding
Advanced Submerge-Arc Welding Technology
Shape
Conical, Square, Round, Octagonal Optional
Galvanizing Standard
En ISO 1461 or Equivalent
Welding Standard
En 1011 or Equivalent
Design Standard
En 40-5 or Equivalent
Wind Speed
7m/S or Customized
Transport Package
Bubble Packing+Blanket Packing
Production Capacity
5000PCS/Month
Product Description
Product Parameters H6M+L0.6M Traffic Light Pole Diameter
Lamp pole Steel:Q235B Diameter of upright rod: 220-280mm Thickness of upright rod: 5mm Diameter of horizontal rod: 100-200mm Thickness of horizontal rod: 4mm Diameter of bottom flange: 550mm Thickness of bottom flange: 18mm Connecting flange: 300*300mm Welding mode: Automatic submerged-arc welding Anti-corrosion treatment: Pickling + internal and external hot galvanization + passivation + electrostatic plastic spraying Thickness of zinc coating: ≥80um Thickness of sprayed plastic coating: >=100 um Appearance: Smooth surface, hardness >= 2H
| Traffic light: Form: Combination of red, green, and yellow Housing: Aluminum alloy or PC Dimensions: 1050*350mm Light source: Full screen or arrow Diameter of single lamp: 300,400mm Power: 5-24W Voltage: 220V Weight: About 10KG Sign: Customization: Yes Material: Aluminum-alloy plate + aluminum slot Category of reflective coating: Super High Level, High Level, Diamond Level Background color: Yellow, blue, or white Thickness: 1.2,1.5,2,3
|
Main Pole Height:From 6M to 6.8M at 5-10mm thickness for Options. |
Cantilever Length:From 3METER to 14M at 4-8mm thickness for Options. |
ShapeConical, octagonal, square, cylinder |
MaterialUsually Q235B/A36,then Q345B/A572,Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, ST52 for option. |
Surface treatmentHot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required. |
Production ProcessRaw material test → Cutting →Molding or bending →Welding (longitudinal )→Dimension verify →Flange welding →Hole drilling →Calibration → Galvanization or powder coating ,painting →Recalibration →Thread →Packages |
Manufactured Pictures
Product Advantages Top-Quality Raw Material Options: Choose from a premium selection of steel plates including Q235B, Q345, Q355, and GR460.
Mill Certificate Assurance: Every material comes with a certified Mill Certificate, complete with a stamp and signature, ensuring authenticity. Precision Steel Thickness: Inspection tolerance is less than 0.1mm for unmatched accuracy.
Standards Compliance: Meets ASTM A36 equivalent to Q235B.
European Standard Compliance: Adheres to EN 10025 specifications. Advanced Welding Inspection: Magnetic and ultrasonic methods ensure superior weld quality.
AWS Compliance: Conforms to AWS D1.1 standards.
European Welding Standards: Meets EN1090-2 requirements. Superior Galvanization: Hot dip galvanizing thickness averages over 86UM.
Chinese Galvanization Standard: Complies with GB/T13912-2002.
American Standard for Galvanizing: Complies with ASTM A123.
European Galvanizing Standard: Adheres to ENSIO 1461. Durable Powder Coating: Thickness exceeds 100UM for long-lasting protection.
Chinese Powder Coating Standard: Meets GB/T 3181-2008.
American Powder Coating Standard: Complies with ASTM D339-83. Company Profile
Project Cases
>>
