Welcome to visit

Plastic Bottle Recycling Line Plastic Bottle Recycle Machine

US$40,000.00
1 Set
US$35,000.00
2-4 Sets
US$30,000.00
5+ Sets

Basic Info.

Model NO.
TS-RECYCLE
Screw
Single-Screw
Automation
Automation
Computerized
Computerized
Certification
QS, ISO9001:2008, CE
Application
PE PP Pet PVC Waste Plastic
Voltage
220-440V
Rotating Blade Qua
8
Fixed Blade Quantity
4
Turning Diameter
450mm
Sifter Hole Diameter
12mm
Moving Blade Speed
400r/Min
Center Height
1500mm
Intelligent Temperature Controller
Omron
Electric Applicant
Schneider or Siemens
Power
55kw
Capacity
300-1000kg/H
Transport Package
Standred Sea Packing
Specification
25m*1m*4m
Trademark
TONGSAN
Origin
Shandong China
Production Capacity
3sets/ Month, 300/500/1000 Kg/H

Product Description

1.OUR PRODUCTS:

PVC PET PP PE film washing line/recycle plastic machine/machine to recycle plastics bottle
HGMS series plastic cleaning machine is designed to clean recycled plastic woven sack and plastic farm film, the machine is widely used for PET,PP,PE plastic cleaning and plastic bottle cleaning. Developing on the basis of advanced technology, the machine has advantages of stable performance, high output, energy efficiency, small floor area and good appearance. We can produce the machine according to client requirement.
Application Recycling the waste plastic,
PP PE PET PVC the waste plastic film cleaning machine
Capacity 300/500/1000 kg/h
rotating blade quantity 8
fixed blade quantity 4
turning diameter 450mm
feed inlet diameter 600*600mm
sifter hole diameter 12mm
miving blade speed 400r/min
center height 1500mm
motor power 55kw
heating power 70kw
material PP PE PVC PET, waste plastic film
screw quantity 3-5
screw length 3000mm
screw diameter 350mm
size 28000mm
weight 40000kg
pot volume 15000L

Each parts of machinery:
1,
 Belt conveyer
2,
 Crusher (with water cleaning)
3,
 Screw conveyer
4,
 Cleaning device
5,
 Material conveyer
6,
 Bottom material laundry
7,
 Screw conveyer
8,
 Surface material laundry

Label stripper:
Washing machine:
BE OUR CLIENT:
WHY CHOOSE US:
Certificate:
FAQ:
