US$3,000.00-15,000.00
|
1 Set
(MOQ)
|
Basic Info.
Type
Hard Plastic Crusher
Knife Classification
Piece Knife Crusher
Knife Roll
Solid Knife Roller
Computerized
Non-Computerized
Certification
CE, ISO9001:2008
Application
Crush Plastic Lump, Pipe, Film, etc
Electric
Siemens or Delixi
Machine Color
Blue, Grey, White or According to Requirement
Transport Package
Wooden Case Film Packing
Trademark
Sunrise Machinery
Production Capacity
100 Set /Year
Packaging & Delivery
Package Size
400.00cm * 180.00cm * 200.00cm
Package Gross Weight
2000.000kg
Product Description
Product Description
Crusher Features :1. Easy to operate, low electricty consumption & durable and low noise.
2. Uses high quality steel material especially for making cutter of the crushers.
3. Blades base is made of high quality steel, hard to be broken and damaged; Blades base structure is stable and durable
4. Easy to clean and maintain: The hopper, crusher room,blades and screen can be removed and mounted easily.
5. Less occupied area.
6. Sunrise Machinery can also produce the crusher accoring Client requirment.
Description of crusher:
(1) Designed for plastics. The plastic crusher has been designed exclusively for efficient recycling of polymer materials.
(2) Energy saving. A Single Shaft Shredder followed by a grinder/granulator is a solution that is very energy effective. Compared to a solution with a single large grinder/granulator for the job, the Single Shaft Shredder in combination with a optimized grinder/granulator do the job much more effective.
(3) V-CUT cutting technology. The unique V-CUT Technology, is a combination of V-knife cutting angle, cutting speed and sequential cutting. It provides a best shredding solution for plastic materials.V-CUT provides a sheer and smooth cut with low stress and therefore requires less motor power.
(4) Hydraulic PUSHing system. The pneumatic PUSH-system is auto-regulating, efficiently absorbing vibrations and mechanical stress that occur in tough applications. The special hopper design allows material to feed directly into the rotor.
(5) Special gear box design. The Single Shaft Shredder design contains no compromises. Its unique cutting technology together with a Special gearbox requires lower motor power for the job, minimizing energy consumption.
(6) Easy cleaning/access. The design puts handling in focus. Cleaning the machine for new materials or colors is easy. Just remove a front side plate, and you have quick access to the machine's interior.
(7) Screenless operation. As the material is cut into uniform pieces, the Single Shaft Shredder operates with & without a screen, although screens can be installed as an option when smaller chip sizes are required.
(8) Easy maintenance. The front opening makes it possible to access the rotor of the machine fast and easily. All knives, rotating and fixed are easy accessible. The rotating knives are reversible and are of cassette type, simplifying maintenance.
Specification:
Model
| PC400
| PC500
| PC600
| PC800
| PC1000
|
Diameter of rotating blade (mm)
| 250
| 250
| 380
| 400
| 650
|
Quantity of rotating blade
| 12
| 12
| 18
| 24
| 24
|
Speed of rotating blade (mm)
| 560
| 560
| 560
| 560
| 560
|
Quantity of fixed blade
| 2
| 2
| 4
| 4
| 4
|
Diameter of screening sieve hole (mm)
| φ10
| φ10
| φ10
| φ10
| φ10
|
Capacity (kg/h)
| 80-100
| 120-150
| 250-350
| 400-500
| 700-800
|
Power (kw)
| 7.5
| 11
| 18.5
| 30
| 55
|
Size of the feeding inlet (mm)
| 260×400
| 320×500
| 400×600
| 420×800
| 600×1000
|
Weight(kg)
| 650
| 650
| 1200
| 1500
| 2000
|
HDPE Pipe Crusher
Plastic Film Bag Drum Bottle Crusher
Plastic Shredder and Crusher in Combination:
Plastic Grinder, Shredder
The single shaft plastic shredder machine is mainly used in handling PE PP PVC ABS lumps, pipe, baled film, etc.
This single shaft plastic shredder machine is new designed especially for shredding various big solid materials, unmanageable materials, plastic container and barrel, plastic film, plastic pipe, fiber and paper which the normal crusher can not handle.
This plastic shredder machine has the advantages of stable running lower noise and big torque...
The materials are pushed into the shredding chamber by hydraulic. Independent drive system and solid structure make the running stably.
Shredder Features:
1)Precisely processed combined frame made of extra-thick plates; Lange-angle, hexagon prism of power slewing axis; Big hopper with big caliber for feeding big material
2)PLC control system with automatic overload protection and auto reverse switch
3)Unique hydraulic pushing system accelerates the shredding speed, for light material particularly
4)Each dynamic blades has four cutting edges which enable reutilization after being abraded, by rotating 90 degree
5)Each fixed blades has four cutting edges which enable reutilization after being abraded, by rotating 180 degree
6)Quiet operation at low speed
7)Screen perforation is adjustable according to customers' requirement
8)The shredders can be adjusted according to customer specific requirements for throughput volume, material to be processed, etc.
Model | SR-S600 | SR-S800 | SR-S1000 | SR-S1200 | SR-S1500 |
Shaft Length (mm) | 600 | 800 | 1000 | 1200 | 1500 |
Shaft Diameter (mm) | 220 | 400 | 400 | 400 | 400 |
Main Motor (KW) | 18.5 | 37 | 45 / 55 | 55/75 | 75/90 |
Hydraulic Power (KW) | 2.2 | 2.2 | 2.2 | 5.5 | 5.5 |
Rotary Blades (PC) | 26 | 46 | 58 | 70 | 90 |
Fixed Blades (PC) | 2 | 2 | 2 | 3 | 3 |
Capacity (kg/h) | 200-300 | 400-600 | 700-1000 | 900-1200 | 1300-1600 |
Machine Picrtures:
Plastic Granulating Machine
Plastic Recycling Machines Shipping to Oversea Customers:
Welcome to contact us for more details.
>>
