ANSI 55-2 Porcelain / Ceramic Pin Insulator for High Voltage Transmission Line

US$0.50-10.00 500 Pieces (MOQ)

Basic Info.

Model NO.
ANSI 55-2
Structure
Pin Insulator
Usage
High Voltage Power Transmission, Insulation
Connection Method
Trough Type
Certification
ISO9001
Color
Brown
Brand
Tkbl
OEM
Accepted
Delivery Time
45-60 Days
Loading Port
Shenzhen
Packing
Wooden Case
Transport Package
Wooden Pallet
Specification
As per customer specified
Trademark
TKBL
Origin
Liling, China
HS Code
8546209090
Production Capacity
50000tons/Year

Product Description

ANSI 55-2 Porcelain / Ceramic pin Insulator for High Voltage Transmission Line
specifications
1. original insulator producer
2. superior properties of low and medium temperature resistance;
3. strong aging resistance;
4. nice appearance & long service time.
5. comman glaze and semi-conductor glaze, color brown and gray both available.
6. free sample, professional porcelain insulator supplier.

Product Description
SPOOL INSULATORS
ANSI
Class		 Main dimension (mm) Mechanical Load (N) Flashover Voltsge (kN) Weight (kg)
Fig No. H h D d d1 d2 R Dry Wet
Vertical Horizontal
R-8 7 32 57 40 40 17.5 7 7 15 918 1.3
R-6 6 80 70 40 40 18 7 7 240 12 18 1350 3.9
R-2 5 76 80 54 54 17.5 17.5 17.5 18 2040 5.9
R-1 5 54 57 39 39 17.5 11 11 18 918 2.4
1617 4 65 76 46 46 17.5 9 9 9000 20 9 9 3.9
1617-1 4 65 78 17.5 17.5 17.5
1617-2 4 67 73 16 14.3 14.3
1618-1 4 75 89 52 52 17 13 13 10000 20 9 9
1618-2 4 75 89 52 52 17 12.5 12.5 13000 25 12 12
1618-3 4 88 95 22 16 16
