| US$8,000.00 | 1 SET (MOQ) |
| LTY-25 | LTY-35 | |||
Injection system | Screw Diameter | Mm | 25 | 28 |
Theoretical injection volume | Cm3 | 54 | 74 | |
Shot weight | g(ps) | 50 | 70 | |
Injection pressure | kgf/cm2 | 1850 | 1475 | |
Injection speed | Cm3/sec | 42 | 58 | |
Screw speed | Rpm | 160 | 180 | |
Barrel heating power | kw | 2.9 | 2.9 | |
Clamping force | T | 30 | 35 | |
Clamping unit | Open stroke | Mm | 160 | 180 |
Min mold height | Mm | 100/160 | 100/180 | |
Max mold height | Mm | 260*320 | 300/380 | |
Mold size | Mm | 430*290 | 550*410 | |
Space between tie-bar | Mm | 320*180 | 370*230 | |
Eject stroke | T | 1.3 | 1.3 | |
Ejector stroke | Mm | 40 | 40 | |
Ejector pin No | Pc | 1 | 1 | |
Others | Hydraulic pressure | Kgf/cm2 | 160 | 160 |
Motor power | Kw | 4 | 4.5 | |
Machine size | M | 1.3*0.85*1.9 | 1.35*1*2.3 | |
Machine weight | T | 1 | 1.5 | |
