Experience Perfection: Our Laser Tubes Set The Standard

Product Description

Product Feature
1. Stability: the raw glass tube body is imported. We are the uique manufacture for adopting advanced foreign technology to use metal-glass sealing technology on CO2 laser tube.
2.Power: the H series CO2 laser tube uses imported mirror and lens. The power is 40% higher than other laser tube with the same length.
3. Long lifespan: the catalyst coating on discharge tube with uique electrode processing makes the laser output more stable, ensures the working life around 8000 hours, avoid power weaking after long time working.
3. Laser Beam: adjustable optical resonant cavity, super laser beam quality. The beam is upt to TEM00 the power is stable, it is competitive for industrial application.
4. Appearance: all accessories are processed by imported equipments , unique metal and glass tube sealing technology,standardized production.
Technical-parameters

Model: PRR-1200	Length:1200mm	Outer Diameter:80mm
Output Power: 80-90w	Rated Power: 80W	Ignitioin Voltage: 20-22KV
Ignition Current:6-8MA	Working Voltage: 14-15KV	Working Current: 20-25MA

Additional Info.
Working Principle: high-pressure discharge stimulate high concentration CO2 to generate laser.
Laser Wave Length: 10.6um.
Laser Mode:low order mode.
Water-Cooling:purified water, appropriate temperature 10-35ºC.
Working Environment:temperature 5-35ºC, humidity 10-60%, clean environment, no serious pollution.
Working Current:16~22mA is appropriate (excessive current will affect laser power and laser tube lifetime.
Safety Demand:CO2 laser tube outputs invisible light, positive with high pressure, if necessary, eyewear is essential.
Laser State: Laser power will be attenuated when the laser tube is used at a certain time; If the laser is pink, it is in normal condition; if the laser is white, it means the laser power is attenuate. ( Laser tube is consumable, please change a new one when it can't meet demand due to attenuation. )
Laser State:
1, There are two points to support the laser tube at two sides, when you install the laser tube, the two points should be in 1/4 of the laser tube;
2,On the basis of cooling water above-in and below-out, if you rotate the laser tube slightly, it will affect laser spot and laser power.
One more thing we have a professional team so that we have excellent skills. Belive in us means believe in youself. A real choice is waiting for you!!!
Packing&shipping FAQ:
1.Q: Are you factory or trading company?
A: We are factory with 13 years experience. We are the only one manufacture that not only produces laser machine, but also produce laser tube in China.
2.Q: Where is your facotry located in? How can I visit there?
A: Our factory is located in Heqing town, Pudong district, Shanghai, China, 18KM from Shanghai Pudong International Airport. We can pick you up from Airport and arrive at factory within 20 mins. You are warmly welcome to visit us!!!
3.Q: What's your MOQ?
A: We don't have MOQ. No matter 1set order or 100sets order, we will give you support with our heart and soul.
4.Q: How do your factory do regarding quality control?
A: Quality is priority. Each YH laser machine will be tested by 24 items.After all the 24 items passed, then our QA do 48~72 hours reliability test.
Our laser machines has gained CE, FDA authentication.
Our GM said, producing unqualified products is producing rubbish. YH people always keep quality in mind.
