SGA30110AH/AHR/AHD High precision surface grinder machine for metal work with CE
| Specification | SGA-30110AH/AHR/AHD |
| Table size(WxL) | 1020x405mm |
| Max.longitudinal travel | 1130mm |
| Cross travel | 340mm |
| Max.distance from spindle center to table | 580mm |
| Magnetic chuck size | 400x1000mm |
| Speed of table longitudinal movement | 7-23m/min |
| Table transerve movement/ Auto feed | 0.1-8mm/min |
| Table transerve movement/ Repid speed | 990mm/min |
| Table transerve movement/ Feed of handlwheel | 0.02mm/div. |
| Wheelhead vertical movement/ Auto feed | -(H/R mode)0.005/0.01/0.02/0.03/0.04/0.05(only for D model)mm/stroke |
| Wheelhead vertical movement/Repid speed | -(H mode)610(only for R model)480(only for D model)mm/min |
| Wheelhead vertical movement/ Feed of handlwheel | 0.005mm/div. |
| Grinding wheel Speed 50Hz | 1450rpm |
| Grinding wheel Speed 60Hz | 1750rpm |
| Grinding wheel (ODxWxID) Size | 350x40x127mm |
| Spindle motor | 4/5.5kw |
| Hydranlic Motor | 2.2kw |
| Coolant pump motor | 0.09kw |
| Cross feed motor | 0.04kw |
| Max.loading capacity of table(include magnetic chuck) | 600kg |
| Total rated power | 7.5/9kw |
| Gross weight | 3900kg |
| Packing dimensions(LxWxH) | 2960x2250x2220mm |
